summary
Summary of physics quantities from a simulation or an experiment. Dynamic quantities are either taken at given time slices (indicated in the “time” vector) or time-averaged over an interval (in such case the “time_width” of the interval is indicated and the “time” vector represents the end of each time interval).
New in version 3.22.0: lifecycle status active
Changed in version 4.2.0.
ids_propertiesstructure
See common IDS structure reference: ids_properties.
typestructureType of data contained in the dataset
Type of data contained in the dataset
This is an identifier. See data_type_identifier for the available options.
type/nameSTR_0DShort string identifier
Short string identifier
type/indexINT_0DInteger identifier (enumeration index within a list). […] (click to expand)
Integer identifier (enumeration index within a list). Private identifier values must be indicated by a negative index.
type/descriptionSTR_0DVerbose description
Verbose description
machineSTR_0DName of the experimental device to which this data is related […] (click to expand)
Name of the experimental device to which this data is related (if relevant)
pulseINT_0DPulse number to which this data is related (if relevant)
Pulse number to which this data is related (if relevant)
pulse_time_beginSTR_0DDate and time (UTC) at which the pulse started on the experiment […] (click to expand)
Date and time (UTC) at which the pulse started on the experiment (if relevant), expressed in a human readable form (ISO 8601) : the format of the string shall be : YYYY-MM-DDTHH:MM:SSZ. Example : 2020-07-24T14:19:00Z
pulse_time_begin_epochstructureTime at which the pulse started on the experiment (if relevant), […] (click to expand)
Time at which the pulse started on the experiment (if relevant), expressed in Unix Epoch time represented as two integers: seconds, plus additionally elapsed nanoseconds
pulse_time_begin_epoch/secondsINT_0DElapsed seconds since the Unix Epoch time (01/01/1970 00:00:00 […] (click to expand)
Elapsed seconds since the Unix Epoch time (01/01/1970 00:00:00 UTC)
pulse_time_begin_epoch/nanosecondsINT_0DElapsed nanoseconds since Unix Epoch time in seconds
Elapsed nanoseconds since Unix Epoch time in seconds
pulse_time_end_epochstructureTime at which the pulse ended on the experiment (if relevant), […] (click to expand)
Time at which the pulse ended on the experiment (if relevant), expressed in Unix Epoch time represented as two integers: seconds, plus additionally elapsed nanoseconds
pulse_time_end_epoch/secondsINT_0DElapsed seconds since the Unix Epoch time (01/01/1970 00:00:00 […] (click to expand)
Elapsed seconds since the Unix Epoch time (01/01/1970 00:00:00 UTC)
pulse_time_end_epoch/nanosecondsINT_0DElapsed nanoseconds since Unix Epoch time in seconds
Elapsed nanoseconds since Unix Epoch time in seconds
pulse_processing_time_beginSTR_0DFor experimental processed data, date and time (UTC) at which […] (click to expand)
For experimental processed data, date and time (UTC) at which the pulse data processing started on the experiment (if relevant), expressed in a human readable form (ISO 8601) : the format of the string shall be : YYYY-MM-DDTHH:MM:SSZ. Example : 2020-07-24T14:19:00Z
descriptionSTR_0DDescription of the simulation or the pulse
Description of the simulation or the pulse
simulationstructureDescription of the general characteristics of the simulation, […] (click to expand)
Description of the general characteristics of the simulation, if this dataset has been produced by a simulation
simulation/time_begin ⇹sFLT_0DStart time (relative to the beginning of the pulse)
Start time (relative to the beginning of the pulse)
simulation/time_step ⇹sFLT_0DTime interval between main steps, e.g. […] (click to expand)
Time interval between main steps, e.g. storage step (if relevant and constant)
simulation/time_end ⇹sFLT_0DStop time (relative to the beginning of the pulse)
Stop time (relative to the beginning of the pulse)
simulation/workflowSTR_0DDescription of the workflow which has been used to produce this […] (click to expand)
Description of the workflow which has been used to produce this data entry
tagstructureTag qualifying this data entry (or a list of data entries)
Tag qualifying this data entry (or a list of data entries)
tag/nameSTR_0DName of the tag
Name of the tag
configurationstructureDevice configuration (the content may be device-specific)
Device configuration (the content may be device-specific)
configuration/valueSTR_0DValue
Value
configuration/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
magnetic_shear_flagstructureMagnetic field shear indicator for stellarators: 0 for shearless […] (click to expand)
Magnetic field shear indicator for stellarators: 0 for shearless stellarators (W7-A, W7-AS, W7-X); 1, otherwise. See [Stroth U. et al 1996 Nucl. Fusion 36 1063]
magnetic_shear_flag/valueINT_0DValue
Value
magnetic_shear_flag/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
stationary_phase_flagstructureThis flag is set to one if the pulse is in a stationary phase […] (click to expand)
This flag is set to one if the pulse is in a stationary phase from the point of the of the energy content (if the time derivative of the energy dW/dt can be neglected when calculating tau_E as W/(P_abs-dW/dt).)
stationary_phase_flag/value(:)INT_1DValue
Value
stationary_phase_flag/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
midplanestructureChoice of midplane definition (use the lowest index number if […] (click to expand)
Choice of midplane definition (use the lowest index number if more than one value is relevant)
This is an identifier. See midplane_identifier for the available options.
midplane/nameSTR_0DShort string identifier
Short string identifier
midplane/indexINT_0DInteger identifier (enumeration index within a list). […] (click to expand)
Integer identifier (enumeration index within a list). Private identifier values must be indicated by a negative index.
midplane/descriptionSTR_0DVerbose description
Verbose description
composition1structureRatios of the volume-averaged density (inside LCFS) of each ion […] (click to expand)
Ratios of the volume-averaged density (inside LCFS) of each ion species to the volume-averaged electron density, taken at the time of maximum electron density during the pulse
composition/hydrogenstructureHydrogen (H)
Hydrogen (H)
composition/hydrogen/value ⇹1FLT_0DValue
Value
composition/hydrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
composition/deuteriumstructureDeuterium (D)
Deuterium (D)
composition/deuterium/value ⇹1FLT_0DValue
Value
composition/deuterium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
composition/tritiumstructureTritium (T)
Tritium (T)
composition/tritium/value ⇹1FLT_0DValue
Value
composition/tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
composition/deuterium_tritiumstructureFictitious DT single species with mass 2.5, used in some simulations
Fictitious DT single species with mass 2.5, used in some simulations
composition/deuterium_tritium/value ⇹1FLT_0DValue
Value
composition/deuterium_tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
composition/helium_3structureHelium isotope with 3 nucleons (3He)
Helium isotope with 3 nucleons (3He)
composition/helium_3/value ⇹1FLT_0DValue
Value
composition/helium_3/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
composition/helium_4structureHelium isotope with 4 nucleons (4He)
Helium isotope with 4 nucleons (4He)
composition/helium_4/value ⇹1FLT_0DValue
Value
composition/helium_4/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
composition/berylliumstructureBeryllium (Be)
Beryllium (Be)
composition/beryllium/value ⇹1FLT_0DValue
Value
composition/beryllium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
composition/boronstructureBoron (B)
Boron (B)
composition/boron/value ⇹1FLT_0DValue
Value
composition/boron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
composition/lithiumstructureLithium (Li)
Lithium (Li)
composition/lithium/value ⇹1FLT_0DValue
Value
composition/lithium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
composition/carbonstructureCarbon (C)
Carbon (C)
composition/carbon/value ⇹1FLT_0DValue
Value
composition/carbon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
composition/nitrogenstructureNitrogen (N)
Nitrogen (N)
composition/nitrogen/value ⇹1FLT_0DValue
Value
composition/nitrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
composition/neonstructureNeon (Ne)
Neon (Ne)
composition/neon/value ⇹1FLT_0DValue
Value
composition/neon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
composition/argonstructureArgon (Ar)
Argon (Ar)
composition/argon/value ⇹1FLT_0DValue
Value
composition/argon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
composition/xenonstructureXenon (Xe)
Xenon (Xe)
composition/xenon/value ⇹1FLT_0DValue
Value
composition/xenon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
composition/oxygenstructureOxygen (O)
Oxygen (O)
composition/oxygen/value ⇹1FLT_0DValue
Value
composition/oxygen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
composition/tungstenstructureTungsten (W)
Tungsten (W)
composition/tungsten/value ⇹1FLT_0DValue
Value
composition/tungsten/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
composition/ironstructureIron (Fe)
Iron (Fe)
composition/iron/value ⇹1FLT_0DValue
Value
composition/iron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
composition/kryptonstructureKrypton (Kr)
Krypton (Kr)
composition/krypton/value ⇹1FLT_0DValue
Value
composition/krypton/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantitiesstructureVarious global quantities derived from the profiles
Various global quantities derived from the profiles
global_quantities/ipAstructureTotal plasma current (toroidal component). […] (click to expand)
Total plasma current (toroidal component). Positive sign means anti-clockwise when viewed from above.
global_quantities/ip/value(:) ⇹AFLT_1DValue
Value
global_quantities/ip/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/current_non_inductiveAstructureTotal non-inductive current (toroidal component). […] (click to expand)
Total non-inductive current (toroidal component). Positive sign means anti-clockwise when viewed from above.
global_quantities/current_non_inductive/value(:) ⇹AFLT_1DValue
Value
global_quantities/current_non_inductive/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/current_bootstrapAstructureBootstrap current (toroidal component). […] (click to expand)
Bootstrap current (toroidal component). Positive sign means anti-clockwise when viewed from above.
global_quantities/current_bootstrap/value(:) ⇹AFLT_1DValue
Value
global_quantities/current_bootstrap/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/current_ohmAstructureOhmic current (toroidal component). […] (click to expand)
Ohmic current (toroidal component). Positive sign means anti-clockwise when viewed from above.
global_quantities/current_ohm/value(:) ⇹AFLT_1DValue
Value
global_quantities/current_ohm/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/current_alignmentAstructureFigure of merit of the alignment of the current profile sources, […] (click to expand)
Figure of merit of the alignment of the current profile sources, defined in the following reference: http://iopscience.iop.org/article/10.1088/0029-5515/43/7/318
global_quantities/current_alignment/value(:) ⇹AFLT_1DValue
Value
global_quantities/current_alignment/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/v_loopVstructureLCFS loop voltage (positive value drives positive ohmic current […] (click to expand)
LCFS loop voltage (positive value drives positive ohmic current that flows anti-clockwise when viewed from above)
global_quantities/v_loop/value(:) ⇹VFLT_1DValue
Value
global_quantities/v_loop/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/li_31structureInternal inductance. […] (click to expand)
Internal inductance. The li_3 definition is used, i.e. li_3 = 2/R0/mu0^2/Ip^2 * int(Bp^2 dV).
Changed in version 4.0.0: Renamed from li
global_quantities/li_3/value(:) ⇹1FLT_1DValue
Value
global_quantities/li_3/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/li_3_mhd1structureInternal inductance as determined by an equilibrium reconstruction […] (click to expand)
Internal inductance as determined by an equilibrium reconstruction code. Use this only when the li node above is used for another estimation method and there is a need to store a second value of li (determined by an equilibrium reconstruction code). The li_3 definition is used, i.e. li_3 = 2/R0/mu0^2/Ip^2 * int(Bp^2 dV).
Changed in version 4.0.0: Renamed from li_mhd
global_quantities/li_3_mhd/value(:) ⇹1FLT_1DValue
Value
global_quantities/li_3_mhd/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/beta_tor1structureToroidal beta, defined as the volume-averaged total perpendicular […] (click to expand)
Toroidal beta, defined as the volume-averaged total perpendicular pressure divided by (B0^2/(2*mu0)), i.e. beta_toroidal = 2 mu0 int(p dV) / V / B0^2
global_quantities/beta_tor/value(:) ⇹1FLT_1DValue
Value
global_quantities/beta_tor/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/beta_tor_mhd1structureToroidal beta, using the pressure determined by an equilibrium […] (click to expand)
Toroidal beta, using the pressure determined by an equilibrium reconstruction code
global_quantities/beta_tor_mhd/value(:) ⇹1FLT_1DValue
Value
global_quantities/beta_tor_mhd/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/beta_tor_norm1structureNormalized toroidal beta, defined as 100 \* beta_tor \* a[m] […] (click to expand)
Normalized toroidal beta, defined as 100 * beta_tor * a[m] * B0 [T] / ip [MA]
global_quantities/beta_tor_norm/value(:) ⇹1FLT_1DValue
Value
global_quantities/beta_tor_norm/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/beta_tor_norm_mhd1structureNormalized toroidal beta, using the pressure determined by an […] (click to expand)
Normalized toroidal beta, using the pressure determined by an equilibrium reconstruction code
global_quantities/beta_tor_norm_mhd/value(:) ⇹1FLT_1DValue
Value
global_quantities/beta_tor_norm_mhd/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/beta_tor_thermal_norm1structureNormalized toroidal beta from thermal pressure only, defined […] (click to expand)
Normalized toroidal beta from thermal pressure only, defined as 100 * beta_tor_thermal * a[m] * B0 [T] / ip [MA]
global_quantities/beta_tor_thermal_norm/value(:) ⇹1FLT_1DValue
Value
global_quantities/beta_tor_thermal_norm/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/beta_pol1structurePoloidal beta. […] (click to expand)
Poloidal beta. Defined as betap = 4 int(p dV) / [R_0 * mu_0 * Ip^2]
global_quantities/beta_pol/value(:) ⇹1FLT_1DValue
Value
global_quantities/beta_pol/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/beta_pol_mhd1structurePoloidal beta estimated from the pressure determined by an equilibrium […] (click to expand)
Poloidal beta estimated from the pressure determined by an equilibrium reconstruction code. Defined as betap = 4 int(p dV) / [R_0 * mu_0 * Ip^2]
global_quantities/beta_pol_mhd/value(:) ⇹1FLT_1DValue
Value
global_quantities/beta_pol_mhd/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/energy_diamagneticJstructurePlasma diamagnetic energy content = 3/2 \* integral over the […] (click to expand)
Plasma diamagnetic energy content = 3/2 * integral over the plasma volume of the total perpendicular pressure
global_quantities/energy_diamagnetic/value(:) ⇹JFLT_1DValue
Value
global_quantities/energy_diamagnetic/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/denergy_diamagnetic_dtWstructureTime derivative of the diamagnetic plasma energy content
Time derivative of the diamagnetic plasma energy content
global_quantities/denergy_diamagnetic_dt/value(:) ⇹WFLT_1DValue
Value
global_quantities/denergy_diamagnetic_dt/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/energy_totalJstructurePlasma energy content = 3/2 \* integral over the plasma volume […] (click to expand)
Plasma energy content = 3/2 * integral over the plasma volume of the total kinetic pressure
global_quantities/energy_total/value(:) ⇹JFLT_1DValue
Value
global_quantities/energy_total/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/energy_mhdJstructurePlasma energy content = 3/2 \* integral over the plasma volume […] (click to expand)
Plasma energy content = 3/2 * integral over the plasma volume of the total kinetic pressure (pressure determined by an equilibrium reconstruction code)
global_quantities/energy_mhd/value(:) ⇹JFLT_1DValue
Value
global_quantities/energy_mhd/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/energy_thermalJstructureThermal plasma energy content = 3/2 \* integral over the plasma […] (click to expand)
Thermal plasma energy content = 3/2 * integral over the plasma volume of the thermal pressure
global_quantities/energy_thermal/value(:) ⇹JFLT_1DValue
Value
global_quantities/energy_thermal/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/energy_ion_total_thermalJstructureThermal ion plasma energy content (sum over the ion species) […] (click to expand)
Thermal ion plasma energy content (sum over the ion species) = 3/2 * integral over the plasma volume of the thermal ion pressure
global_quantities/energy_ion_total_thermal/value(:) ⇹JFLT_1DValue
Value
global_quantities/energy_ion_total_thermal/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/energy_electrons_thermalJstructureThermal electron plasma energy content = 3/2 \* integral over […] (click to expand)
Thermal electron plasma energy content = 3/2 * integral over the plasma volume of the thermal electron pressure
global_quantities/energy_electrons_thermal/value(:) ⇹JFLT_1DValue
Value
global_quantities/energy_electrons_thermal/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/denergy_thermal_dtWstructureTime derivative of the thermal plasma energy content
Time derivative of the thermal plasma energy content
global_quantities/denergy_thermal_dt/value(:) ⇹WFLT_1DValue
Value
global_quantities/denergy_thermal_dt/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/energy_b_field_polJstructurePoloidal magnetic plasma energy content = 1/(2.mu0) \* integral […] (click to expand)
Poloidal magnetic plasma energy content = 1/(2.mu0) * integral over the plasma volume of b_field_pol^2
global_quantities/energy_b_field_pol/value(:) ⇹JFLT_1DValue
Value
global_quantities/energy_b_field_pol/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/energy_fast_perpendicularJstructureFast particles perpendicular energy content = 3/2 \* integral […] (click to expand)
Fast particles perpendicular energy content = 3/2 * integral over the plasma volume of the fast perpendicular pressure
global_quantities/energy_fast_perpendicular/value(:) ⇹JFLT_1DValue
Value
global_quantities/energy_fast_perpendicular/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/energy_fast_parallelJstructureFast particles parallel energy content = 3/2 \* integral over […] (click to expand)
Fast particles parallel energy content = 3/2 * integral over the plasma volume of the fast parallel pressure
global_quantities/energy_fast_parallel/value(:) ⇹JFLT_1DValue
Value
global_quantities/energy_fast_parallel/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/volumem^3structureVolume of the confined plasma
Volume of the confined plasma
global_quantities/volume/value(:) ⇹m^3FLT_1DValue
Value
global_quantities/volume/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/h_modestructureH-mode flag: 0 when the plasma is in L-mode and 1 when in H-mode
H-mode flag: 0 when the plasma is in L-mode and 1 when in H-mode
global_quantities/h_mode/value(:)INT_1DValue
Value
global_quantities/h_mode/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/r0mstructureReference major radius where the vacuum toroidal magnetic field […] (click to expand)
Reference major radius where the vacuum toroidal magnetic field is given (usually a fixed position such as the middle of the vessel at the equatorial midplane)
global_quantities/r0/value ⇹mFLT_0DValue
Value
global_quantities/r0/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/b0TstructureVacuum toroidal field at R0. […] (click to expand)
Vacuum toroidal field at R0. Positive sign means anti-clockwise when viewed from above. The product R0B0 must be consistent with the b_tor_vacuum_r field of the tf IDS.
global_quantities/b0/value(:) ⇹TFLT_1DValue
Value
global_quantities/b0/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/fusion_gain1structureFusion gain : ratio of the power provided by fusion reactions […] (click to expand)
Fusion gain : ratio of the power provided by fusion reactions to the auxiliary power needed to heat the plasma. Often noted as Q in the litterature.
global_quantities/fusion_gain/value(:) ⇹1FLT_1DValue
Value
global_quantities/fusion_gain/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/h_981structureEnergy confinement time enhancement factor over the IPB98(y,2) […] (click to expand)
Energy confinement time enhancement factor over the IPB98(y,2) scaling
global_quantities/h_98/value(:) ⇹1FLT_1DValue
Value
global_quantities/h_98/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/tau_energysstructureEnergy confinement time
Energy confinement time
global_quantities/tau_energy/value(:) ⇹sFLT_1DValue
Value
global_quantities/tau_energy/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/tau_heliumsstructureHelium confinement time
Helium confinement time
global_quantities/tau_helium/value(:) ⇹sFLT_1DValue
Value
global_quantities/tau_helium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/tau_resistivesstructureCurrent diffusion characteristic time
Current diffusion characteristic time
global_quantities/tau_resistive/value(:) ⇹sFLT_1DValue
Value
global_quantities/tau_resistive/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/tau_energy_98sstructureEnergy confinement time estimated from the IPB98(y,2) scaling
Energy confinement time estimated from the IPB98(y,2) scaling
global_quantities/tau_energy_98/value(:) ⇹sFLT_1DValue
Value
global_quantities/tau_energy_98/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/ratio_tau_helium_fuel1structureRatio of Helium confinement time to fuel confinement time
Ratio of Helium confinement time to fuel confinement time
global_quantities/ratio_tau_helium_fuel/value(:) ⇹1FLT_1DValue
Value
global_quantities/ratio_tau_helium_fuel/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/resistanceohmstructurePlasma electric resistance
Plasma electric resistance
global_quantities/resistance/value(:) ⇹ohmFLT_1DValue
Value
global_quantities/resistance/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/q_951structureq at the 95% poloidal flux surface (only positive when toroidal […] (click to expand)
q at the 95% poloidal flux surface (only positive when toroidal current and magnetic field are in same direction)
global_quantities/q_95/value(:) ⇹1FLT_1DValue
Value
global_quantities/q_95/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/power_ohmWstructureOhmic power
Ohmic power
global_quantities/power_ohm/value(:) ⇹WFLT_1DValue
Value
global_quantities/power_ohm/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/power_steadyWstructureTotal power coupled to the plasma minus dW/dt (correcting from […] (click to expand)
Total power coupled to the plasma minus dW/dt (correcting from transient energy content)
global_quantities/power_steady/value(:) ⇹WFLT_1DValue
Value
global_quantities/power_steady/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/power_radiatedWstructureTotal radiated power
Total radiated power
global_quantities/power_radiated/value(:) ⇹WFLT_1DValue
Value
global_quantities/power_radiated/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/power_radiated_inside_lcfsWstructureRadiated power from the plasma inside the Last Closed Flux Surface
Radiated power from the plasma inside the Last Closed Flux Surface
global_quantities/power_radiated_inside_lcfs/value(:) ⇹WFLT_1DValue
Value
global_quantities/power_radiated_inside_lcfs/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/power_radiated_outside_lcfsWstructureRadiated power from the plasma outside the Last Closed Flux Surface
Radiated power from the plasma outside the Last Closed Flux Surface
global_quantities/power_radiated_outside_lcfs/value(:) ⇹WFLT_1DValue
Value
global_quantities/power_radiated_outside_lcfs/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/power_lineWstructureRadiated power from line radiation
Radiated power from line radiation
global_quantities/power_line/value(:) ⇹WFLT_1DValue
Value
global_quantities/power_line/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/power_bremsstrahlungWstructureRadiated power from Bremsstrahlung
Radiated power from Bremsstrahlung
global_quantities/power_bremsstrahlung/value(:) ⇹WFLT_1DValue
Value
global_quantities/power_bremsstrahlung/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/power_synchrotronWstructureRadiated power from synchrotron radiation
Radiated power from synchrotron radiation
global_quantities/power_synchrotron/value(:) ⇹WFLT_1DValue
Value
global_quantities/power_synchrotron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/power_lossWstructurePower through separatrix
Power through separatrix
global_quantities/power_loss/value(:) ⇹WFLT_1DValue
Value
global_quantities/power_loss/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/greenwald_fraction1structureGreenwald fraction =line_average/n_e/value divided by (global_quantities/ip/value […] (click to expand)
Greenwald fraction =line_average/n_e/value divided by (global_quantities/ip/value *1e6 * pi * minor_radius^2)
global_quantities/greenwald_fraction/value(:) ⇹1FLT_1DValue
Value
global_quantities/greenwald_fraction/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/fusion_fluenceJstructureFusion fluence : power provided by fusion reactions, integrated […] (click to expand)
Fusion fluence : power provided by fusion reactions, integrated over time since the beginning of the pulse
global_quantities/fusion_fluence/value(:) ⇹JFLT_1DValue
Value
global_quantities/fusion_fluence/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
global_quantities/psi_external_averageWbstructureAverage (over the plasma poloidal cross section) plasma poloidal […] (click to expand)
Average (over the plasma poloidal cross section) plasma poloidal magnetic flux produced by all toroidal loops (active coils and passive loops) but the plasma, given by the following formula : int(psi_loops.j_tor.dS) / Ip
global_quantities/psi_external_average/value(:) ⇹WbFLT_1DValue
Value
global_quantities/psi_external_average/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
localstructurePlasma parameter values at different locations
Plasma parameter values at different locations
local/magnetic_axisstructureParameters at magnetic axis
Parameters at magnetic axis
local/magnetic_axis/positionstructureRadial position at which physics quantities are evaluated
Radial position at which physics quantities are evaluated
local/magnetic_axis/position/rho_tor_norm(:) ⇹1FLT_1DNormalized toroidal flux coordinate. […] (click to expand)
Normalized toroidal flux coordinate. The normalizing value for rho_tor_norm, is the toroidal flux coordinate at the equilibrium boundary (LCFS or 99.x % of the LCFS in case of a fixed boundary equilibium calculation, see time_slice/boundary/b_flux_pol_norm in the equilibrium IDS)
local/magnetic_axis/position/rho_tor(:) ⇹mFLT_1DToroidal flux coordinate. […] (click to expand)
Toroidal flux coordinate. rho_tor = sqrt(b_flux_tor/(pi*b0)) ~ sqrt(pi*r^2*b0/(pi*b0)) ~ r [m]. The toroidal field used in its definition is indicated under global_quantities/b0
local/magnetic_axis/position/psi(:) ⇹WbFLT_1DPoloidal magnetic flux
Poloidal magnetic flux
local/magnetic_axis/position/r(:) ⇹mFLT_1DMajor radius
Major radius
local/magnetic_axis/position/z(:) ⇹mFLT_1DHeight
Height
local/magnetic_axis/t_eeVstructureElectron temperature
Electron temperature
local/magnetic_axis/t_e/value(:) ⇹eVFLT_1DValue
Value
local/magnetic_axis/t_e/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/t_i_averageeVstructureIon temperature (average over ion species)
Ion temperature (average over ion species)
local/magnetic_axis/t_i_average/value(:) ⇹eVFLT_1DValue
Value
local/magnetic_axis/t_i_average/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/n_em^-3structureElectron density
Electron density
local/magnetic_axis/n_e/value(:) ⇹m^-3FLT_1DValue
Value
local/magnetic_axis/n_e/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/n_im^-3structureIon density per species
Ion density per species
local/magnetic_axis/n_i/hydrogenstructureHydrogen (H)
Hydrogen (H)
local/magnetic_axis/n_i/hydrogen/value(:) ⇹m^-3FLT_1DValue
Value
local/magnetic_axis/n_i/hydrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/n_i/deuteriumstructureDeuterium (D)
Deuterium (D)
local/magnetic_axis/n_i/deuterium/value(:) ⇹m^-3FLT_1DValue
Value
local/magnetic_axis/n_i/deuterium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/n_i/tritiumstructureTritium (T)
Tritium (T)
local/magnetic_axis/n_i/tritium/value(:) ⇹m^-3FLT_1DValue
Value
local/magnetic_axis/n_i/tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/n_i/deuterium_tritiumstructureFictitious DT single species with mass 2.5, used in some simulations
Fictitious DT single species with mass 2.5, used in some simulations
local/magnetic_axis/n_i/deuterium_tritium/value(:) ⇹m^-3FLT_1DValue
Value
local/magnetic_axis/n_i/deuterium_tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/n_i/helium_3structureHelium isotope with 3 nucleons (3He)
Helium isotope with 3 nucleons (3He)
local/magnetic_axis/n_i/helium_3/value(:) ⇹m^-3FLT_1DValue
Value
local/magnetic_axis/n_i/helium_3/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/n_i/helium_4structureHelium isotope with 4 nucleons (4He)
Helium isotope with 4 nucleons (4He)
local/magnetic_axis/n_i/helium_4/value(:) ⇹m^-3FLT_1DValue
Value
local/magnetic_axis/n_i/helium_4/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/n_i/berylliumstructureBeryllium (Be)
Beryllium (Be)
local/magnetic_axis/n_i/beryllium/value(:) ⇹m^-3FLT_1DValue
Value
local/magnetic_axis/n_i/beryllium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/n_i/boronstructureBoron (B)
Boron (B)
local/magnetic_axis/n_i/boron/value(:) ⇹m^-3FLT_1DValue
Value
local/magnetic_axis/n_i/boron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/n_i/lithiumstructureLithium (Li)
Lithium (Li)
local/magnetic_axis/n_i/lithium/value(:) ⇹m^-3FLT_1DValue
Value
local/magnetic_axis/n_i/lithium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/n_i/carbonstructureCarbon (C)
Carbon (C)
local/magnetic_axis/n_i/carbon/value(:) ⇹m^-3FLT_1DValue
Value
local/magnetic_axis/n_i/carbon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/n_i/nitrogenstructureNitrogen (N)
Nitrogen (N)
local/magnetic_axis/n_i/nitrogen/value(:) ⇹m^-3FLT_1DValue
Value
local/magnetic_axis/n_i/nitrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/n_i/neonstructureNeon (Ne)
Neon (Ne)
local/magnetic_axis/n_i/neon/value(:) ⇹m^-3FLT_1DValue
Value
local/magnetic_axis/n_i/neon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/n_i/argonstructureArgon (Ar)
Argon (Ar)
local/magnetic_axis/n_i/argon/value(:) ⇹m^-3FLT_1DValue
Value
local/magnetic_axis/n_i/argon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/n_i/xenonstructureXenon (Xe)
Xenon (Xe)
local/magnetic_axis/n_i/xenon/value(:) ⇹m^-3FLT_1DValue
Value
local/magnetic_axis/n_i/xenon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/n_i/oxygenstructureOxygen (O)
Oxygen (O)
local/magnetic_axis/n_i/oxygen/value(:) ⇹m^-3FLT_1DValue
Value
local/magnetic_axis/n_i/oxygen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/n_i/tungstenstructureTungsten (W)
Tungsten (W)
local/magnetic_axis/n_i/tungsten/value(:) ⇹m^-3FLT_1DValue
Value
local/magnetic_axis/n_i/tungsten/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/n_i/ironstructureIron (Fe)
Iron (Fe)
local/magnetic_axis/n_i/iron/value(:) ⇹m^-3FLT_1DValue
Value
local/magnetic_axis/n_i/iron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/n_i/kryptonstructureKrypton (Kr)
Krypton (Kr)
local/magnetic_axis/n_i/krypton/value(:) ⇹m^-3FLT_1DValue
Value
local/magnetic_axis/n_i/krypton/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/n_i_totalm^-3structureTotal ion density (sum over species)
Total ion density (sum over species)
local/magnetic_axis/n_i_total/value(:) ⇹m^-3FLT_1DValue
Value
local/magnetic_axis/n_i_total/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/zeff1structureEffective charge
Effective charge
local/magnetic_axis/zeff/value(:) ⇹1FLT_1DValue
Value
local/magnetic_axis/zeff/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/momentum_phikg.m.s^-1structureTotal plasma toroidal momentum, summed over ion species and electrons
Total plasma toroidal momentum, summed over ion species and electrons
Changed in version 3.42.0: Renamed from momentum_tor
local/magnetic_axis/momentum_phi/value(:) ⇹kg.m.s^-1FLT_1DValue
Value
local/magnetic_axis/momentum_phi/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/velocity_phim.s^-1structureIon toroidal rotation velocity, per species
Ion toroidal rotation velocity, per species
Changed in version 3.42.0: Renamed from velocity_tor
local/magnetic_axis/velocity_phi/hydrogenstructureHydrogen (H)
Hydrogen (H)
local/magnetic_axis/velocity_phi/hydrogen/value(:) ⇹m.s^-1FLT_1DValue
Value
local/magnetic_axis/velocity_phi/hydrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/velocity_phi/deuteriumstructureDeuterium (D)
Deuterium (D)
local/magnetic_axis/velocity_phi/deuterium/value(:) ⇹m.s^-1FLT_1DValue
Value
local/magnetic_axis/velocity_phi/deuterium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/velocity_phi/tritiumstructureTritium (T)
Tritium (T)
local/magnetic_axis/velocity_phi/tritium/value(:) ⇹m.s^-1FLT_1DValue
Value
local/magnetic_axis/velocity_phi/tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/velocity_phi/deuterium_tritiumstructureFictitious DT single species with mass 2.5, used in some simulations
Fictitious DT single species with mass 2.5, used in some simulations
local/magnetic_axis/velocity_phi/deuterium_tritium/value(:) ⇹m.s^-1FLT_1DValue
Value
local/magnetic_axis/velocity_phi/deuterium_tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/velocity_phi/helium_3structureHelium isotope with 3 nucleons (3He)
Helium isotope with 3 nucleons (3He)
local/magnetic_axis/velocity_phi/helium_3/value(:) ⇹m.s^-1FLT_1DValue
Value
local/magnetic_axis/velocity_phi/helium_3/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/velocity_phi/helium_4structureHelium isotope with 4 nucleons (4He)
Helium isotope with 4 nucleons (4He)
local/magnetic_axis/velocity_phi/helium_4/value(:) ⇹m.s^-1FLT_1DValue
Value
local/magnetic_axis/velocity_phi/helium_4/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/velocity_phi/berylliumstructureBeryllium (Be)
Beryllium (Be)
local/magnetic_axis/velocity_phi/beryllium/value(:) ⇹m.s^-1FLT_1DValue
Value
local/magnetic_axis/velocity_phi/beryllium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/velocity_phi/lithiumstructureLithium (Li)
Lithium (Li)
local/magnetic_axis/velocity_phi/lithium/value(:) ⇹m.s^-1FLT_1DValue
Value
local/magnetic_axis/velocity_phi/lithium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/velocity_phi/carbonstructureCarbon (C)
Carbon (C)
local/magnetic_axis/velocity_phi/carbon/value(:) ⇹m.s^-1FLT_1DValue
Value
local/magnetic_axis/velocity_phi/carbon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/velocity_phi/nitrogenstructureNitrogen (N)
Nitrogen (N)
local/magnetic_axis/velocity_phi/nitrogen/value(:) ⇹m.s^-1FLT_1DValue
Value
local/magnetic_axis/velocity_phi/nitrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/velocity_phi/neonstructureNeon (Ne)
Neon (Ne)
local/magnetic_axis/velocity_phi/neon/value(:) ⇹m.s^-1FLT_1DValue
Value
local/magnetic_axis/velocity_phi/neon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/velocity_phi/argonstructureArgon (Ar)
Argon (Ar)
local/magnetic_axis/velocity_phi/argon/value(:) ⇹m.s^-1FLT_1DValue
Value
local/magnetic_axis/velocity_phi/argon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/velocity_phi/xenonstructureXenon (Xe)
Xenon (Xe)
local/magnetic_axis/velocity_phi/xenon/value(:) ⇹m.s^-1FLT_1DValue
Value
local/magnetic_axis/velocity_phi/xenon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/velocity_phi/oxygenstructureOxygen (O)
Oxygen (O)
local/magnetic_axis/velocity_phi/oxygen/value(:) ⇹m.s^-1FLT_1DValue
Value
local/magnetic_axis/velocity_phi/oxygen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/velocity_phi/tungstenstructureTungsten (W)
Tungsten (W)
local/magnetic_axis/velocity_phi/tungsten/value(:) ⇹m.s^-1FLT_1DValue
Value
local/magnetic_axis/velocity_phi/tungsten/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/velocity_phi/ironstructureIron (Fe)
Iron (Fe)
local/magnetic_axis/velocity_phi/iron/value(:) ⇹m.s^-1FLT_1DValue
Value
local/magnetic_axis/velocity_phi/iron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/velocity_phi/kryptonstructureKrypton (Kr)
Krypton (Kr)
local/magnetic_axis/velocity_phi/krypton/value(:) ⇹m.s^-1FLT_1DValue
Value
local/magnetic_axis/velocity_phi/krypton/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/q1structureSafety factor (only positive when toroidal current and magnetic […] (click to expand)
Safety factor (only positive when toroidal current and magnetic field are in same direction)
local/magnetic_axis/q/value(:) ⇹1FLT_1DValue
Value
local/magnetic_axis/q/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/magnetic_shear1structureMagnetic shear, defined as rho_tor/q . […] (click to expand)
Magnetic shear, defined as rho_tor/q . dq/drho_tor
local/magnetic_axis/magnetic_shear/value(:) ⇹1FLT_1DValue
Value
local/magnetic_axis/magnetic_shear/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/b_field_torTstructureToroidal magnetic field
Toroidal magnetic field
Changed in version 4.0.0: Renamed from b_field
Deprecated since version 4.1.0.
local/magnetic_axis/b_field_tor/value(:) ⇹TFLT_1DValue
Value
local/magnetic_axis/b_field_tor/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/b_field_phiTstructureToroidal magnetic field
Toroidal magnetic field
Changed in version 4.1.0: Renamed from b_field_tor
local/magnetic_axis/b_field_phi/value(:) ⇹TFLT_1DValue
Value
local/magnetic_axis/b_field_phi/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/magnetic_axis/e_field_parallelV.m^-1structureAverage on the magnetic surface of (e_field.b_field) / B0, where […] (click to expand)
Average on the magnetic surface of (e_field.b_field) / B0, where B0 is global_quantities/b0/value
local/magnetic_axis/e_field_parallel/value(:) ⇹V.m^-1FLT_1DValue
Value
local/magnetic_axis/e_field_parallel/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrixstructureParameters at separatrix (intersection of the separatrix and […] (click to expand)
Parameters at separatrix (intersection of the separatrix and the outboard midplane)
local/separatrix/positionstructureRadial position at which physics quantities are evaluated
Radial position at which physics quantities are evaluated
local/separatrix/position/rho_tor_norm(:) ⇹1FLT_1DNormalized toroidal flux coordinate. […] (click to expand)
Normalized toroidal flux coordinate. The normalizing value for rho_tor_norm, is the toroidal flux coordinate at the equilibrium boundary (LCFS or 99.x % of the LCFS in case of a fixed boundary equilibium calculation, see time_slice/boundary/b_flux_pol_norm in the equilibrium IDS)
local/separatrix/position/rho_tor(:) ⇹mFLT_1DToroidal flux coordinate. […] (click to expand)
Toroidal flux coordinate. rho_tor = sqrt(b_flux_tor/(pi*b0)) ~ sqrt(pi*r^2*b0/(pi*b0)) ~ r [m]. The toroidal field used in its definition is indicated under global_quantities/b0
local/separatrix/position/psi(:) ⇹WbFLT_1DPoloidal magnetic flux
Poloidal magnetic flux
local/separatrix/t_eeVstructureElectron temperature
Electron temperature
local/separatrix/t_e/value(:) ⇹eVFLT_1DValue
Value
local/separatrix/t_e/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/t_i_averageeVstructureIon temperature (average over ion species)
Ion temperature (average over ion species)
local/separatrix/t_i_average/value(:) ⇹eVFLT_1DValue
Value
local/separatrix/t_i_average/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/n_em^-3structureElectron density
Electron density
local/separatrix/n_e/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix/n_e/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/n_im^-3structureIon density per species
Ion density per species
local/separatrix/n_i/hydrogenstructureHydrogen (H)
Hydrogen (H)
local/separatrix/n_i/hydrogen/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix/n_i/hydrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/n_i/deuteriumstructureDeuterium (D)
Deuterium (D)
local/separatrix/n_i/deuterium/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix/n_i/deuterium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/n_i/tritiumstructureTritium (T)
Tritium (T)
local/separatrix/n_i/tritium/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix/n_i/tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/n_i/deuterium_tritiumstructureFictitious DT single species with mass 2.5, used in some simulations
Fictitious DT single species with mass 2.5, used in some simulations
local/separatrix/n_i/deuterium_tritium/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix/n_i/deuterium_tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/n_i/helium_3structureHelium isotope with 3 nucleons (3He)
Helium isotope with 3 nucleons (3He)
local/separatrix/n_i/helium_3/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix/n_i/helium_3/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/n_i/helium_4structureHelium isotope with 4 nucleons (4He)
Helium isotope with 4 nucleons (4He)
local/separatrix/n_i/helium_4/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix/n_i/helium_4/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/n_i/berylliumstructureBeryllium (Be)
Beryllium (Be)
local/separatrix/n_i/beryllium/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix/n_i/beryllium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/n_i/boronstructureBoron (B)
Boron (B)
local/separatrix/n_i/boron/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix/n_i/boron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/n_i/lithiumstructureLithium (Li)
Lithium (Li)
local/separatrix/n_i/lithium/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix/n_i/lithium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/n_i/carbonstructureCarbon (C)
Carbon (C)
local/separatrix/n_i/carbon/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix/n_i/carbon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/n_i/nitrogenstructureNitrogen (N)
Nitrogen (N)
local/separatrix/n_i/nitrogen/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix/n_i/nitrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/n_i/neonstructureNeon (Ne)
Neon (Ne)
local/separatrix/n_i/neon/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix/n_i/neon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/n_i/argonstructureArgon (Ar)
Argon (Ar)
local/separatrix/n_i/argon/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix/n_i/argon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/n_i/xenonstructureXenon (Xe)
Xenon (Xe)
local/separatrix/n_i/xenon/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix/n_i/xenon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/n_i/oxygenstructureOxygen (O)
Oxygen (O)
local/separatrix/n_i/oxygen/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix/n_i/oxygen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/n_i/tungstenstructureTungsten (W)
Tungsten (W)
local/separatrix/n_i/tungsten/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix/n_i/tungsten/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/n_i/ironstructureIron (Fe)
Iron (Fe)
local/separatrix/n_i/iron/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix/n_i/iron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/n_i/kryptonstructureKrypton (Kr)
Krypton (Kr)
local/separatrix/n_i/krypton/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix/n_i/krypton/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/n_i_totalm^-3structureTotal ion density (sum over species)
Total ion density (sum over species)
local/separatrix/n_i_total/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix/n_i_total/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/zeff1structureEffective charge
Effective charge
local/separatrix/zeff/value(:) ⇹1FLT_1DValue
Value
local/separatrix/zeff/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/momentum_phikg.m.s^-1structureTotal plasma toroidal momentum, summed over ion species and electrons
Total plasma toroidal momentum, summed over ion species and electrons
Changed in version 3.42.0: Renamed from momentum_tor
local/separatrix/momentum_phi/value(:) ⇹kg.m.s^-1FLT_1DValue
Value
local/separatrix/momentum_phi/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/velocity_phim.s^-1structureIon toroidal rotation velocity, per species
Ion toroidal rotation velocity, per species
Changed in version 3.42.0: Renamed from velocity_tor
local/separatrix/velocity_phi/hydrogenstructureHydrogen (H)
Hydrogen (H)
local/separatrix/velocity_phi/hydrogen/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix/velocity_phi/hydrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/velocity_phi/deuteriumstructureDeuterium (D)
Deuterium (D)
local/separatrix/velocity_phi/deuterium/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix/velocity_phi/deuterium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/velocity_phi/tritiumstructureTritium (T)
Tritium (T)
local/separatrix/velocity_phi/tritium/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix/velocity_phi/tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/velocity_phi/deuterium_tritiumstructureFictitious DT single species with mass 2.5, used in some simulations
Fictitious DT single species with mass 2.5, used in some simulations
local/separatrix/velocity_phi/deuterium_tritium/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix/velocity_phi/deuterium_tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/velocity_phi/helium_3structureHelium isotope with 3 nucleons (3He)
Helium isotope with 3 nucleons (3He)
local/separatrix/velocity_phi/helium_3/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix/velocity_phi/helium_3/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/velocity_phi/helium_4structureHelium isotope with 4 nucleons (4He)
Helium isotope with 4 nucleons (4He)
local/separatrix/velocity_phi/helium_4/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix/velocity_phi/helium_4/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/velocity_phi/berylliumstructureBeryllium (Be)
Beryllium (Be)
local/separatrix/velocity_phi/beryllium/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix/velocity_phi/beryllium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/velocity_phi/lithiumstructureLithium (Li)
Lithium (Li)
local/separatrix/velocity_phi/lithium/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix/velocity_phi/lithium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/velocity_phi/carbonstructureCarbon (C)
Carbon (C)
local/separatrix/velocity_phi/carbon/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix/velocity_phi/carbon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/velocity_phi/nitrogenstructureNitrogen (N)
Nitrogen (N)
local/separatrix/velocity_phi/nitrogen/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix/velocity_phi/nitrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/velocity_phi/neonstructureNeon (Ne)
Neon (Ne)
local/separatrix/velocity_phi/neon/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix/velocity_phi/neon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/velocity_phi/argonstructureArgon (Ar)
Argon (Ar)
local/separatrix/velocity_phi/argon/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix/velocity_phi/argon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/velocity_phi/xenonstructureXenon (Xe)
Xenon (Xe)
local/separatrix/velocity_phi/xenon/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix/velocity_phi/xenon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/velocity_phi/oxygenstructureOxygen (O)
Oxygen (O)
local/separatrix/velocity_phi/oxygen/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix/velocity_phi/oxygen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/velocity_phi/tungstenstructureTungsten (W)
Tungsten (W)
local/separatrix/velocity_phi/tungsten/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix/velocity_phi/tungsten/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/velocity_phi/ironstructureIron (Fe)
Iron (Fe)
local/separatrix/velocity_phi/iron/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix/velocity_phi/iron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/velocity_phi/kryptonstructureKrypton (Kr)
Krypton (Kr)
local/separatrix/velocity_phi/krypton/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix/velocity_phi/krypton/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/q1structureSafety factor
Safety factor
local/separatrix/q/value(:) ⇹1FLT_1DValue
Value
local/separatrix/q/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/magnetic_shear1structureMagnetic shear, defined as rho_tor/q . […] (click to expand)
Magnetic shear, defined as rho_tor/q . dq/drho_tor
local/separatrix/magnetic_shear/value(:) ⇹1FLT_1DValue
Value
local/separatrix/magnetic_shear/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix/e_field_parallelV.m^-1structureAverage on the magnetic surface of (e_field.b_field) / B0, where […] (click to expand)
Average on the magnetic surface of (e_field.b_field) / B0, where B0 is global_quantities/b0/value
local/separatrix/e_field_parallel/value(:) ⇹V.m^-1FLT_1DValue
Value
local/separatrix/e_field_parallel/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_averagestructureFlux surface averaged parameters at separatrix (flux-surface […] (click to expand)
Flux surface averaged parameters at separatrix (flux-surface average over the entire core-SOL boundary separatrix)
local/separatrix_average/positionstructureRadial position at which physics quantities are evaluated
Radial position at which physics quantities are evaluated
local/separatrix_average/position/rho_tor_norm(:) ⇹1FLT_1DNormalized toroidal flux coordinate. […] (click to expand)
Normalized toroidal flux coordinate. The normalizing value for rho_tor_norm, is the toroidal flux coordinate at the equilibrium boundary (LCFS or 99.x % of the LCFS in case of a fixed boundary equilibium calculation, see time_slice/boundary/b_flux_pol_norm in the equilibrium IDS)
local/separatrix_average/position/rho_tor(:) ⇹mFLT_1DToroidal flux coordinate. […] (click to expand)
Toroidal flux coordinate. rho_tor = sqrt(b_flux_tor/(pi*b0)) ~ sqrt(pi*r^2*b0/(pi*b0)) ~ r [m]. The toroidal field used in its definition is indicated under global_quantities/b0
local/separatrix_average/position/psi(:) ⇹WbFLT_1DPoloidal magnetic flux
Poloidal magnetic flux
local/separatrix_average/t_eeVstructureElectron temperature
Electron temperature
local/separatrix_average/t_e/value(:) ⇹eVFLT_1DValue
Value
local/separatrix_average/t_e/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/t_i_averageeVstructureIon temperature (average over ion species)
Ion temperature (average over ion species)
local/separatrix_average/t_i_average/value(:) ⇹eVFLT_1DValue
Value
local/separatrix_average/t_i_average/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/n_em^-3structureElectron density
Electron density
local/separatrix_average/n_e/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix_average/n_e/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/n_im^-3structureIon density per species
Ion density per species
local/separatrix_average/n_i/hydrogenstructureHydrogen (H)
Hydrogen (H)
local/separatrix_average/n_i/hydrogen/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix_average/n_i/hydrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/n_i/deuteriumstructureDeuterium (D)
Deuterium (D)
local/separatrix_average/n_i/deuterium/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix_average/n_i/deuterium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/n_i/tritiumstructureTritium (T)
Tritium (T)
local/separatrix_average/n_i/tritium/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix_average/n_i/tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/n_i/deuterium_tritiumstructureFictitious DT single species with mass 2.5, used in some simulations
Fictitious DT single species with mass 2.5, used in some simulations
local/separatrix_average/n_i/deuterium_tritium/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix_average/n_i/deuterium_tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/n_i/helium_3structureHelium isotope with 3 nucleons (3He)
Helium isotope with 3 nucleons (3He)
local/separatrix_average/n_i/helium_3/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix_average/n_i/helium_3/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/n_i/helium_4structureHelium isotope with 4 nucleons (4He)
Helium isotope with 4 nucleons (4He)
local/separatrix_average/n_i/helium_4/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix_average/n_i/helium_4/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/n_i/berylliumstructureBeryllium (Be)
Beryllium (Be)
local/separatrix_average/n_i/beryllium/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix_average/n_i/beryllium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/n_i/boronstructureBoron (B)
Boron (B)
local/separatrix_average/n_i/boron/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix_average/n_i/boron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/n_i/lithiumstructureLithium (Li)
Lithium (Li)
local/separatrix_average/n_i/lithium/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix_average/n_i/lithium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/n_i/carbonstructureCarbon (C)
Carbon (C)
local/separatrix_average/n_i/carbon/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix_average/n_i/carbon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/n_i/nitrogenstructureNitrogen (N)
Nitrogen (N)
local/separatrix_average/n_i/nitrogen/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix_average/n_i/nitrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/n_i/neonstructureNeon (Ne)
Neon (Ne)
local/separatrix_average/n_i/neon/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix_average/n_i/neon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/n_i/argonstructureArgon (Ar)
Argon (Ar)
local/separatrix_average/n_i/argon/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix_average/n_i/argon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/n_i/xenonstructureXenon (Xe)
Xenon (Xe)
local/separatrix_average/n_i/xenon/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix_average/n_i/xenon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/n_i/oxygenstructureOxygen (O)
Oxygen (O)
local/separatrix_average/n_i/oxygen/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix_average/n_i/oxygen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/n_i/tungstenstructureTungsten (W)
Tungsten (W)
local/separatrix_average/n_i/tungsten/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix_average/n_i/tungsten/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/n_i/ironstructureIron (Fe)
Iron (Fe)
local/separatrix_average/n_i/iron/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix_average/n_i/iron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/n_i/kryptonstructureKrypton (Kr)
Krypton (Kr)
local/separatrix_average/n_i/krypton/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix_average/n_i/krypton/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/n_i_totalm^-3structureTotal ion density (sum over species)
Total ion density (sum over species)
local/separatrix_average/n_i_total/value(:) ⇹m^-3FLT_1DValue
Value
local/separatrix_average/n_i_total/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/zeff1structureEffective charge
Effective charge
local/separatrix_average/zeff/value(:) ⇹1FLT_1DValue
Value
local/separatrix_average/zeff/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/momentum_phikg.m.s^-1structureTotal plasma toroidal momentum, summed over ion species and electrons
Total plasma toroidal momentum, summed over ion species and electrons
Changed in version 3.42.0: Renamed from momentum_tor
local/separatrix_average/momentum_phi/value(:) ⇹kg.m.s^-1FLT_1DValue
Value
local/separatrix_average/momentum_phi/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/velocity_phim.s^-1structureIon toroidal rotation velocity, per species
Ion toroidal rotation velocity, per species
Changed in version 3.42.0: Renamed from velocity_tor
local/separatrix_average/velocity_phi/hydrogenstructureHydrogen (H)
Hydrogen (H)
local/separatrix_average/velocity_phi/hydrogen/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix_average/velocity_phi/hydrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/velocity_phi/deuteriumstructureDeuterium (D)
Deuterium (D)
local/separatrix_average/velocity_phi/deuterium/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix_average/velocity_phi/deuterium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/velocity_phi/tritiumstructureTritium (T)
Tritium (T)
local/separatrix_average/velocity_phi/tritium/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix_average/velocity_phi/tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/velocity_phi/deuterium_tritiumstructureFictitious DT single species with mass 2.5, used in some simulations
Fictitious DT single species with mass 2.5, used in some simulations
local/separatrix_average/velocity_phi/deuterium_tritium/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix_average/velocity_phi/deuterium_tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/velocity_phi/helium_3structureHelium isotope with 3 nucleons (3He)
Helium isotope with 3 nucleons (3He)
local/separatrix_average/velocity_phi/helium_3/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix_average/velocity_phi/helium_3/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/velocity_phi/helium_4structureHelium isotope with 4 nucleons (4He)
Helium isotope with 4 nucleons (4He)
local/separatrix_average/velocity_phi/helium_4/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix_average/velocity_phi/helium_4/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/velocity_phi/berylliumstructureBeryllium (Be)
Beryllium (Be)
local/separatrix_average/velocity_phi/beryllium/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix_average/velocity_phi/beryllium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/velocity_phi/lithiumstructureLithium (Li)
Lithium (Li)
local/separatrix_average/velocity_phi/lithium/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix_average/velocity_phi/lithium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/velocity_phi/carbonstructureCarbon (C)
Carbon (C)
local/separatrix_average/velocity_phi/carbon/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix_average/velocity_phi/carbon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/velocity_phi/nitrogenstructureNitrogen (N)
Nitrogen (N)
local/separatrix_average/velocity_phi/nitrogen/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix_average/velocity_phi/nitrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/velocity_phi/neonstructureNeon (Ne)
Neon (Ne)
local/separatrix_average/velocity_phi/neon/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix_average/velocity_phi/neon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/velocity_phi/argonstructureArgon (Ar)
Argon (Ar)
local/separatrix_average/velocity_phi/argon/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix_average/velocity_phi/argon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/velocity_phi/xenonstructureXenon (Xe)
Xenon (Xe)
local/separatrix_average/velocity_phi/xenon/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix_average/velocity_phi/xenon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/velocity_phi/oxygenstructureOxygen (O)
Oxygen (O)
local/separatrix_average/velocity_phi/oxygen/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix_average/velocity_phi/oxygen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/velocity_phi/tungstenstructureTungsten (W)
Tungsten (W)
local/separatrix_average/velocity_phi/tungsten/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix_average/velocity_phi/tungsten/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/velocity_phi/ironstructureIron (Fe)
Iron (Fe)
local/separatrix_average/velocity_phi/iron/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix_average/velocity_phi/iron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/velocity_phi/kryptonstructureKrypton (Kr)
Krypton (Kr)
local/separatrix_average/velocity_phi/krypton/value(:) ⇹m.s^-1FLT_1DValue
Value
local/separatrix_average/velocity_phi/krypton/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/q1structureSafety factor
Safety factor
local/separatrix_average/q/value(:) ⇹1FLT_1DValue
Value
local/separatrix_average/q/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/magnetic_shear1structureMagnetic shear, defined as rho_tor/q . […] (click to expand)
Magnetic shear, defined as rho_tor/q . dq/drho_tor
local/separatrix_average/magnetic_shear/value(:) ⇹1FLT_1DValue
Value
local/separatrix_average/magnetic_shear/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/separatrix_average/e_field_parallelV.m^-1structureAverage on the magnetic surface of (e_field.b_field) / B0, where […] (click to expand)
Average on the magnetic surface of (e_field.b_field) / B0, where B0 is global_quantities/b0/value
local/separatrix_average/e_field_parallel/value(:) ⇹V.m^-1FLT_1DValue
Value
local/separatrix_average/e_field_parallel/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestalstructureParameters at pedestal top
Parameters at pedestal top
local/pedestal/positionstructureRadial position at which physics quantities are evaluated
Radial position at which physics quantities are evaluated
local/pedestal/position/rho_tor_norm(:) ⇹1FLT_1DNormalized toroidal flux coordinate. […] (click to expand)
Normalized toroidal flux coordinate. The normalizing value for rho_tor_norm, is the toroidal flux coordinate at the equilibrium boundary (LCFS or 99.x % of the LCFS in case of a fixed boundary equilibium calculation, see time_slice/boundary/b_flux_pol_norm in the equilibrium IDS)
local/pedestal/position/rho_tor(:) ⇹mFLT_1DToroidal flux coordinate. […] (click to expand)
Toroidal flux coordinate. rho_tor = sqrt(b_flux_tor/(pi*b0)) ~ sqrt(pi*r^2*b0/(pi*b0)) ~ r [m]. The toroidal field used in its definition is indicated under global_quantities/b0
local/pedestal/position/psi(:) ⇹WbFLT_1DPoloidal magnetic flux
Poloidal magnetic flux
local/pedestal/t_eeVstructureElectron temperature
Electron temperature
local/pedestal/t_e/value(:) ⇹eVFLT_1DValue
Value
local/pedestal/t_e/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/t_i_averageeVstructureIon temperature (average over ion species)
Ion temperature (average over ion species)
local/pedestal/t_i_average/value(:) ⇹eVFLT_1DValue
Value
local/pedestal/t_i_average/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/n_em^-3structureElectron density
Electron density
local/pedestal/n_e/value(:) ⇹m^-3FLT_1DValue
Value
local/pedestal/n_e/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/n_im^-3structureIon density per species
Ion density per species
local/pedestal/n_i/hydrogenstructureHydrogen (H)
Hydrogen (H)
local/pedestal/n_i/hydrogen/value(:) ⇹m^-3FLT_1DValue
Value
local/pedestal/n_i/hydrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/n_i/deuteriumstructureDeuterium (D)
Deuterium (D)
local/pedestal/n_i/deuterium/value(:) ⇹m^-3FLT_1DValue
Value
local/pedestal/n_i/deuterium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/n_i/tritiumstructureTritium (T)
Tritium (T)
local/pedestal/n_i/tritium/value(:) ⇹m^-3FLT_1DValue
Value
local/pedestal/n_i/tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/n_i/deuterium_tritiumstructureFictitious DT single species with mass 2.5, used in some simulations
Fictitious DT single species with mass 2.5, used in some simulations
local/pedestal/n_i/deuterium_tritium/value(:) ⇹m^-3FLT_1DValue
Value
local/pedestal/n_i/deuterium_tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/n_i/helium_3structureHelium isotope with 3 nucleons (3He)
Helium isotope with 3 nucleons (3He)
local/pedestal/n_i/helium_3/value(:) ⇹m^-3FLT_1DValue
Value
local/pedestal/n_i/helium_3/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/n_i/helium_4structureHelium isotope with 4 nucleons (4He)
Helium isotope with 4 nucleons (4He)
local/pedestal/n_i/helium_4/value(:) ⇹m^-3FLT_1DValue
Value
local/pedestal/n_i/helium_4/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/n_i/berylliumstructureBeryllium (Be)
Beryllium (Be)
local/pedestal/n_i/beryllium/value(:) ⇹m^-3FLT_1DValue
Value
local/pedestal/n_i/beryllium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/n_i/boronstructureBoron (B)
Boron (B)
local/pedestal/n_i/boron/value(:) ⇹m^-3FLT_1DValue
Value
local/pedestal/n_i/boron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/n_i/lithiumstructureLithium (Li)
Lithium (Li)
local/pedestal/n_i/lithium/value(:) ⇹m^-3FLT_1DValue
Value
local/pedestal/n_i/lithium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/n_i/carbonstructureCarbon (C)
Carbon (C)
local/pedestal/n_i/carbon/value(:) ⇹m^-3FLT_1DValue
Value
local/pedestal/n_i/carbon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/n_i/nitrogenstructureNitrogen (N)
Nitrogen (N)
local/pedestal/n_i/nitrogen/value(:) ⇹m^-3FLT_1DValue
Value
local/pedestal/n_i/nitrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/n_i/neonstructureNeon (Ne)
Neon (Ne)
local/pedestal/n_i/neon/value(:) ⇹m^-3FLT_1DValue
Value
local/pedestal/n_i/neon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/n_i/argonstructureArgon (Ar)
Argon (Ar)
local/pedestal/n_i/argon/value(:) ⇹m^-3FLT_1DValue
Value
local/pedestal/n_i/argon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/n_i/xenonstructureXenon (Xe)
Xenon (Xe)
local/pedestal/n_i/xenon/value(:) ⇹m^-3FLT_1DValue
Value
local/pedestal/n_i/xenon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/n_i/oxygenstructureOxygen (O)
Oxygen (O)
local/pedestal/n_i/oxygen/value(:) ⇹m^-3FLT_1DValue
Value
local/pedestal/n_i/oxygen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/n_i/tungstenstructureTungsten (W)
Tungsten (W)
local/pedestal/n_i/tungsten/value(:) ⇹m^-3FLT_1DValue
Value
local/pedestal/n_i/tungsten/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/n_i/ironstructureIron (Fe)
Iron (Fe)
local/pedestal/n_i/iron/value(:) ⇹m^-3FLT_1DValue
Value
local/pedestal/n_i/iron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/n_i/kryptonstructureKrypton (Kr)
Krypton (Kr)
local/pedestal/n_i/krypton/value(:) ⇹m^-3FLT_1DValue
Value
local/pedestal/n_i/krypton/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/n_i_totalm^-3structureTotal ion density (sum over species)
Total ion density (sum over species)
local/pedestal/n_i_total/value(:) ⇹m^-3FLT_1DValue
Value
local/pedestal/n_i_total/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/zeff1structureEffective charge
Effective charge
local/pedestal/zeff/value(:) ⇹1FLT_1DValue
Value
local/pedestal/zeff/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/momentum_phikg.m.s^-1structureTotal plasma toroidal momentum, summed over ion species and electrons
Total plasma toroidal momentum, summed over ion species and electrons
Changed in version 3.42.0: Renamed from momentum_tor
local/pedestal/momentum_phi/value(:) ⇹kg.m.s^-1FLT_1DValue
Value
local/pedestal/momentum_phi/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/velocity_phim.s^-1structureIon toroidal rotation velocity, per species
Ion toroidal rotation velocity, per species
Changed in version 3.42.0: Renamed from velocity_tor
local/pedestal/velocity_phi/hydrogenstructureHydrogen (H)
Hydrogen (H)
local/pedestal/velocity_phi/hydrogen/value(:) ⇹m.s^-1FLT_1DValue
Value
local/pedestal/velocity_phi/hydrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/velocity_phi/deuteriumstructureDeuterium (D)
Deuterium (D)
local/pedestal/velocity_phi/deuterium/value(:) ⇹m.s^-1FLT_1DValue
Value
local/pedestal/velocity_phi/deuterium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/velocity_phi/tritiumstructureTritium (T)
Tritium (T)
local/pedestal/velocity_phi/tritium/value(:) ⇹m.s^-1FLT_1DValue
Value
local/pedestal/velocity_phi/tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/velocity_phi/deuterium_tritiumstructureFictitious DT single species with mass 2.5, used in some simulations
Fictitious DT single species with mass 2.5, used in some simulations
local/pedestal/velocity_phi/deuterium_tritium/value(:) ⇹m.s^-1FLT_1DValue
Value
local/pedestal/velocity_phi/deuterium_tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/velocity_phi/helium_3structureHelium isotope with 3 nucleons (3He)
Helium isotope with 3 nucleons (3He)
local/pedestal/velocity_phi/helium_3/value(:) ⇹m.s^-1FLT_1DValue
Value
local/pedestal/velocity_phi/helium_3/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/velocity_phi/helium_4structureHelium isotope with 4 nucleons (4He)
Helium isotope with 4 nucleons (4He)
local/pedestal/velocity_phi/helium_4/value(:) ⇹m.s^-1FLT_1DValue
Value
local/pedestal/velocity_phi/helium_4/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/velocity_phi/berylliumstructureBeryllium (Be)
Beryllium (Be)
local/pedestal/velocity_phi/beryllium/value(:) ⇹m.s^-1FLT_1DValue
Value
local/pedestal/velocity_phi/beryllium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/velocity_phi/lithiumstructureLithium (Li)
Lithium (Li)
local/pedestal/velocity_phi/lithium/value(:) ⇹m.s^-1FLT_1DValue
Value
local/pedestal/velocity_phi/lithium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/velocity_phi/carbonstructureCarbon (C)
Carbon (C)
local/pedestal/velocity_phi/carbon/value(:) ⇹m.s^-1FLT_1DValue
Value
local/pedestal/velocity_phi/carbon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/velocity_phi/nitrogenstructureNitrogen (N)
Nitrogen (N)
local/pedestal/velocity_phi/nitrogen/value(:) ⇹m.s^-1FLT_1DValue
Value
local/pedestal/velocity_phi/nitrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/velocity_phi/neonstructureNeon (Ne)
Neon (Ne)
local/pedestal/velocity_phi/neon/value(:) ⇹m.s^-1FLT_1DValue
Value
local/pedestal/velocity_phi/neon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/velocity_phi/argonstructureArgon (Ar)
Argon (Ar)
local/pedestal/velocity_phi/argon/value(:) ⇹m.s^-1FLT_1DValue
Value
local/pedestal/velocity_phi/argon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/velocity_phi/xenonstructureXenon (Xe)
Xenon (Xe)
local/pedestal/velocity_phi/xenon/value(:) ⇹m.s^-1FLT_1DValue
Value
local/pedestal/velocity_phi/xenon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/velocity_phi/oxygenstructureOxygen (O)
Oxygen (O)
local/pedestal/velocity_phi/oxygen/value(:) ⇹m.s^-1FLT_1DValue
Value
local/pedestal/velocity_phi/oxygen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/velocity_phi/tungstenstructureTungsten (W)
Tungsten (W)
local/pedestal/velocity_phi/tungsten/value(:) ⇹m.s^-1FLT_1DValue
Value
local/pedestal/velocity_phi/tungsten/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/velocity_phi/ironstructureIron (Fe)
Iron (Fe)
local/pedestal/velocity_phi/iron/value(:) ⇹m.s^-1FLT_1DValue
Value
local/pedestal/velocity_phi/iron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/velocity_phi/kryptonstructureKrypton (Kr)
Krypton (Kr)
local/pedestal/velocity_phi/krypton/value(:) ⇹m.s^-1FLT_1DValue
Value
local/pedestal/velocity_phi/krypton/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/q1structureSafety factor
Safety factor
local/pedestal/q/value(:) ⇹1FLT_1DValue
Value
local/pedestal/q/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/magnetic_shear1structureMagnetic shear, defined as rho_tor/q . […] (click to expand)
Magnetic shear, defined as rho_tor/q . dq/drho_tor
local/pedestal/magnetic_shear/value(:) ⇹1FLT_1DValue
Value
local/pedestal/magnetic_shear/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/pedestal/e_field_parallelV.m^-1structureAverage on the magnetic surface of (e_field.b_field) / B0, where […] (click to expand)
Average on the magnetic surface of (e_field.b_field) / B0, where B0 is global_quantities/b0/value
local/pedestal/e_field_parallel/value(:) ⇹V.m^-1FLT_1DValue
Value
local/pedestal/e_field_parallel/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itbstructureParameters at internal transport barrier
Parameters at internal transport barrier
local/itb/positionstructureRadial position at which physics quantities are evaluated
Radial position at which physics quantities are evaluated
local/itb/position/rho_tor_norm(:) ⇹1FLT_1DNormalized toroidal flux coordinate. […] (click to expand)
Normalized toroidal flux coordinate. The normalizing value for rho_tor_norm, is the toroidal flux coordinate at the equilibrium boundary (LCFS or 99.x % of the LCFS in case of a fixed boundary equilibium calculation, see time_slice/boundary/b_flux_pol_norm in the equilibrium IDS)
local/itb/position/rho_tor(:) ⇹mFLT_1DToroidal flux coordinate. […] (click to expand)
Toroidal flux coordinate. rho_tor = sqrt(b_flux_tor/(pi*b0)) ~ sqrt(pi*r^2*b0/(pi*b0)) ~ r [m]. The toroidal field used in its definition is indicated under global_quantities/b0
local/itb/position/psi(:) ⇹WbFLT_1DPoloidal magnetic flux
Poloidal magnetic flux
local/itb/t_eeVstructureElectron temperature
Electron temperature
local/itb/t_e/value(:) ⇹eVFLT_1DValue
Value
local/itb/t_e/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/t_i_averageeVstructureIon temperature (average over ion species)
Ion temperature (average over ion species)
local/itb/t_i_average/value(:) ⇹eVFLT_1DValue
Value
local/itb/t_i_average/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/n_em^-3structureElectron density
Electron density
local/itb/n_e/value(:) ⇹m^-3FLT_1DValue
Value
local/itb/n_e/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/n_im^-3structureIon density per species
Ion density per species
local/itb/n_i/hydrogenstructureHydrogen (H)
Hydrogen (H)
local/itb/n_i/hydrogen/value(:) ⇹m^-3FLT_1DValue
Value
local/itb/n_i/hydrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/n_i/deuteriumstructureDeuterium (D)
Deuterium (D)
local/itb/n_i/deuterium/value(:) ⇹m^-3FLT_1DValue
Value
local/itb/n_i/deuterium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/n_i/tritiumstructureTritium (T)
Tritium (T)
local/itb/n_i/tritium/value(:) ⇹m^-3FLT_1DValue
Value
local/itb/n_i/tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/n_i/deuterium_tritiumstructureFictitious DT single species with mass 2.5, used in some simulations
Fictitious DT single species with mass 2.5, used in some simulations
local/itb/n_i/deuterium_tritium/value(:) ⇹m^-3FLT_1DValue
Value
local/itb/n_i/deuterium_tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/n_i/helium_3structureHelium isotope with 3 nucleons (3He)
Helium isotope with 3 nucleons (3He)
local/itb/n_i/helium_3/value(:) ⇹m^-3FLT_1DValue
Value
local/itb/n_i/helium_3/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/n_i/helium_4structureHelium isotope with 4 nucleons (4He)
Helium isotope with 4 nucleons (4He)
local/itb/n_i/helium_4/value(:) ⇹m^-3FLT_1DValue
Value
local/itb/n_i/helium_4/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/n_i/berylliumstructureBeryllium (Be)
Beryllium (Be)
local/itb/n_i/beryllium/value(:) ⇹m^-3FLT_1DValue
Value
local/itb/n_i/beryllium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/n_i/boronstructureBoron (B)
Boron (B)
local/itb/n_i/boron/value(:) ⇹m^-3FLT_1DValue
Value
local/itb/n_i/boron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/n_i/lithiumstructureLithium (Li)
Lithium (Li)
local/itb/n_i/lithium/value(:) ⇹m^-3FLT_1DValue
Value
local/itb/n_i/lithium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/n_i/carbonstructureCarbon (C)
Carbon (C)
local/itb/n_i/carbon/value(:) ⇹m^-3FLT_1DValue
Value
local/itb/n_i/carbon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/n_i/nitrogenstructureNitrogen (N)
Nitrogen (N)
local/itb/n_i/nitrogen/value(:) ⇹m^-3FLT_1DValue
Value
local/itb/n_i/nitrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/n_i/neonstructureNeon (Ne)
Neon (Ne)
local/itb/n_i/neon/value(:) ⇹m^-3FLT_1DValue
Value
local/itb/n_i/neon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/n_i/argonstructureArgon (Ar)
Argon (Ar)
local/itb/n_i/argon/value(:) ⇹m^-3FLT_1DValue
Value
local/itb/n_i/argon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/n_i/xenonstructureXenon (Xe)
Xenon (Xe)
local/itb/n_i/xenon/value(:) ⇹m^-3FLT_1DValue
Value
local/itb/n_i/xenon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/n_i/oxygenstructureOxygen (O)
Oxygen (O)
local/itb/n_i/oxygen/value(:) ⇹m^-3FLT_1DValue
Value
local/itb/n_i/oxygen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/n_i/tungstenstructureTungsten (W)
Tungsten (W)
local/itb/n_i/tungsten/value(:) ⇹m^-3FLT_1DValue
Value
local/itb/n_i/tungsten/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/n_i/ironstructureIron (Fe)
Iron (Fe)
local/itb/n_i/iron/value(:) ⇹m^-3FLT_1DValue
Value
local/itb/n_i/iron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/n_i/kryptonstructureKrypton (Kr)
Krypton (Kr)
local/itb/n_i/krypton/value(:) ⇹m^-3FLT_1DValue
Value
local/itb/n_i/krypton/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/n_i_totalm^-3structureTotal ion density (sum over species)
Total ion density (sum over species)
local/itb/n_i_total/value(:) ⇹m^-3FLT_1DValue
Value
local/itb/n_i_total/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/zeff1structureEffective charge
Effective charge
local/itb/zeff/value(:) ⇹1FLT_1DValue
Value
local/itb/zeff/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/momentum_phikg.m.s^-1structureTotal plasma toroidal momentum, summed over ion species and electrons
Total plasma toroidal momentum, summed over ion species and electrons
Changed in version 3.42.0: Renamed from momentum_tor
local/itb/momentum_phi/value(:) ⇹kg.m.s^-1FLT_1DValue
Value
local/itb/momentum_phi/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/velocity_phim.s^-1structureIon toroidal rotation velocity, per species
Ion toroidal rotation velocity, per species
Changed in version 3.42.0: Renamed from velocity_tor
local/itb/velocity_phi/hydrogenstructureHydrogen (H)
Hydrogen (H)
local/itb/velocity_phi/hydrogen/value(:) ⇹m.s^-1FLT_1DValue
Value
local/itb/velocity_phi/hydrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/velocity_phi/deuteriumstructureDeuterium (D)
Deuterium (D)
local/itb/velocity_phi/deuterium/value(:) ⇹m.s^-1FLT_1DValue
Value
local/itb/velocity_phi/deuterium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/velocity_phi/tritiumstructureTritium (T)
Tritium (T)
local/itb/velocity_phi/tritium/value(:) ⇹m.s^-1FLT_1DValue
Value
local/itb/velocity_phi/tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/velocity_phi/deuterium_tritiumstructureFictitious DT single species with mass 2.5, used in some simulations
Fictitious DT single species with mass 2.5, used in some simulations
local/itb/velocity_phi/deuterium_tritium/value(:) ⇹m.s^-1FLT_1DValue
Value
local/itb/velocity_phi/deuterium_tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/velocity_phi/helium_3structureHelium isotope with 3 nucleons (3He)
Helium isotope with 3 nucleons (3He)
local/itb/velocity_phi/helium_3/value(:) ⇹m.s^-1FLT_1DValue
Value
local/itb/velocity_phi/helium_3/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/velocity_phi/helium_4structureHelium isotope with 4 nucleons (4He)
Helium isotope with 4 nucleons (4He)
local/itb/velocity_phi/helium_4/value(:) ⇹m.s^-1FLT_1DValue
Value
local/itb/velocity_phi/helium_4/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/velocity_phi/berylliumstructureBeryllium (Be)
Beryllium (Be)
local/itb/velocity_phi/beryllium/value(:) ⇹m.s^-1FLT_1DValue
Value
local/itb/velocity_phi/beryllium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/velocity_phi/lithiumstructureLithium (Li)
Lithium (Li)
local/itb/velocity_phi/lithium/value(:) ⇹m.s^-1FLT_1DValue
Value
local/itb/velocity_phi/lithium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/velocity_phi/carbonstructureCarbon (C)
Carbon (C)
local/itb/velocity_phi/carbon/value(:) ⇹m.s^-1FLT_1DValue
Value
local/itb/velocity_phi/carbon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/velocity_phi/nitrogenstructureNitrogen (N)
Nitrogen (N)
local/itb/velocity_phi/nitrogen/value(:) ⇹m.s^-1FLT_1DValue
Value
local/itb/velocity_phi/nitrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/velocity_phi/neonstructureNeon (Ne)
Neon (Ne)
local/itb/velocity_phi/neon/value(:) ⇹m.s^-1FLT_1DValue
Value
local/itb/velocity_phi/neon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/velocity_phi/argonstructureArgon (Ar)
Argon (Ar)
local/itb/velocity_phi/argon/value(:) ⇹m.s^-1FLT_1DValue
Value
local/itb/velocity_phi/argon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/velocity_phi/xenonstructureXenon (Xe)
Xenon (Xe)
local/itb/velocity_phi/xenon/value(:) ⇹m.s^-1FLT_1DValue
Value
local/itb/velocity_phi/xenon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/velocity_phi/oxygenstructureOxygen (O)
Oxygen (O)
local/itb/velocity_phi/oxygen/value(:) ⇹m.s^-1FLT_1DValue
Value
local/itb/velocity_phi/oxygen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/velocity_phi/tungstenstructureTungsten (W)
Tungsten (W)
local/itb/velocity_phi/tungsten/value(:) ⇹m.s^-1FLT_1DValue
Value
local/itb/velocity_phi/tungsten/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/velocity_phi/ironstructureIron (Fe)
Iron (Fe)
local/itb/velocity_phi/iron/value(:) ⇹m.s^-1FLT_1DValue
Value
local/itb/velocity_phi/iron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/velocity_phi/kryptonstructureKrypton (Kr)
Krypton (Kr)
local/itb/velocity_phi/krypton/value(:) ⇹m.s^-1FLT_1DValue
Value
local/itb/velocity_phi/krypton/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/q1structureSafety factor
Safety factor
local/itb/q/value(:) ⇹1FLT_1DValue
Value
local/itb/q/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/magnetic_shear1structureMagnetic shear, defined as rho_tor/q . […] (click to expand)
Magnetic shear, defined as rho_tor/q . dq/drho_tor
local/itb/magnetic_shear/value(:) ⇹1FLT_1DValue
Value
local/itb/magnetic_shear/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/itb/e_field_parallelV.m^-1structureAverage on the magnetic surface of (e_field.b_field) / B0, where […] (click to expand)
Average on the magnetic surface of (e_field.b_field) / B0, where B0 is global_quantities/b0/value
local/itb/e_field_parallel/value(:) ⇹V.m^-1FLT_1DValue
Value
local/itb/e_field_parallel/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/limiterstructureParameters at the limiter tangency point
Parameters at the limiter tangency point
local/limiter/namestructureName of the limiter or divertor plate. […] (click to expand)
Name of the limiter or divertor plate. Standard names are : LI (resp. LO) for lower inner (resp. outer) plates; UI (resp. UO) for upper inner (resp. outer) plates.
local/limiter/name/valueSTR_0DValue
Value
local/limiter/name/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/limiter/t_eeVstructureElectron temperature
Electron temperature
local/limiter/t_e/value(:) ⇹eVFLT_1DValue
Value
local/limiter/t_e/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/limiter/t_i_averageeVstructureIon temperature (average over ion species)
Ion temperature (average over ion species)
local/limiter/t_i_average/value(:) ⇹eVFLT_1DValue
Value
local/limiter/t_i_average/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/limiter/n_em^-3structureElectron density
Electron density
local/limiter/n_e/value(:) ⇹m^-3FLT_1DValue
Value
local/limiter/n_e/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/limiter/n_im^-3structureIon density per species
Ion density per species
local/limiter/n_i/hydrogenstructureHydrogen (H)
Hydrogen (H)
local/limiter/n_i/hydrogen/value(:) ⇹m^-3FLT_1DValue
Value
local/limiter/n_i/hydrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/limiter/n_i/deuteriumstructureDeuterium (D)
Deuterium (D)
local/limiter/n_i/deuterium/value(:) ⇹m^-3FLT_1DValue
Value
local/limiter/n_i/deuterium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/limiter/n_i/tritiumstructureTritium (T)
Tritium (T)
local/limiter/n_i/tritium/value(:) ⇹m^-3FLT_1DValue
Value
local/limiter/n_i/tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/limiter/n_i/deuterium_tritiumstructureFictitious DT single species with mass 2.5, used in some simulations
Fictitious DT single species with mass 2.5, used in some simulations
local/limiter/n_i/deuterium_tritium/value(:) ⇹m^-3FLT_1DValue
Value
local/limiter/n_i/deuterium_tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/limiter/n_i/helium_3structureHelium isotope with 3 nucleons (3He)
Helium isotope with 3 nucleons (3He)
local/limiter/n_i/helium_3/value(:) ⇹m^-3FLT_1DValue
Value
local/limiter/n_i/helium_3/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/limiter/n_i/helium_4structureHelium isotope with 4 nucleons (4He)
Helium isotope with 4 nucleons (4He)
local/limiter/n_i/helium_4/value(:) ⇹m^-3FLT_1DValue
Value
local/limiter/n_i/helium_4/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/limiter/n_i/berylliumstructureBeryllium (Be)
Beryllium (Be)
local/limiter/n_i/beryllium/value(:) ⇹m^-3FLT_1DValue
Value
local/limiter/n_i/beryllium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/limiter/n_i/boronstructureBoron (B)
Boron (B)
local/limiter/n_i/boron/value(:) ⇹m^-3FLT_1DValue
Value
local/limiter/n_i/boron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/limiter/n_i/lithiumstructureLithium (Li)
Lithium (Li)
local/limiter/n_i/lithium/value(:) ⇹m^-3FLT_1DValue
Value
local/limiter/n_i/lithium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/limiter/n_i/carbonstructureCarbon (C)
Carbon (C)
local/limiter/n_i/carbon/value(:) ⇹m^-3FLT_1DValue
Value
local/limiter/n_i/carbon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/limiter/n_i/nitrogenstructureNitrogen (N)
Nitrogen (N)
local/limiter/n_i/nitrogen/value(:) ⇹m^-3FLT_1DValue
Value
local/limiter/n_i/nitrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/limiter/n_i/neonstructureNeon (Ne)
Neon (Ne)
local/limiter/n_i/neon/value(:) ⇹m^-3FLT_1DValue
Value
local/limiter/n_i/neon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/limiter/n_i/argonstructureArgon (Ar)
Argon (Ar)
local/limiter/n_i/argon/value(:) ⇹m^-3FLT_1DValue
Value
local/limiter/n_i/argon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/limiter/n_i/xenonstructureXenon (Xe)
Xenon (Xe)
local/limiter/n_i/xenon/value(:) ⇹m^-3FLT_1DValue
Value
local/limiter/n_i/xenon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/limiter/n_i/oxygenstructureOxygen (O)
Oxygen (O)
local/limiter/n_i/oxygen/value(:) ⇹m^-3FLT_1DValue
Value
local/limiter/n_i/oxygen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/limiter/n_i/tungstenstructureTungsten (W)
Tungsten (W)
local/limiter/n_i/tungsten/value(:) ⇹m^-3FLT_1DValue
Value
local/limiter/n_i/tungsten/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/limiter/n_i/ironstructureIron (Fe)
Iron (Fe)
local/limiter/n_i/iron/value(:) ⇹m^-3FLT_1DValue
Value
local/limiter/n_i/iron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/limiter/n_i/kryptonstructureKrypton (Kr)
Krypton (Kr)
local/limiter/n_i/krypton/value(:) ⇹m^-3FLT_1DValue
Value
local/limiter/n_i/krypton/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/limiter/n_i_totalm^-3structureTotal ion density (sum over species)
Total ion density (sum over species)
local/limiter/n_i_total/value(:) ⇹m^-3FLT_1DValue
Value
local/limiter/n_i_total/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/limiter/zeff1structureEffective charge
Effective charge
local/limiter/zeff/value(:) ⇹1FLT_1DValue
Value
local/limiter/zeff/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/limiter/flux_expansion1structureMagnetic flux expansion as defined by Stangeby : ratio between […] (click to expand)
Magnetic flux expansion as defined by Stangeby : ratio between the poloidal field at the midplane separatrix and the poloidal field at the strike-point see formula attached, where u means upstream (midplane separatrix) and t means at divertor target (downstream).
Click here for further documentation.
local/limiter/flux_expansion/value(:) ⇹1FLT_1DValue
Value
local/limiter/flux_expansion/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/limiter/power_flux_peakW.m^-2structurePeak power flux on the divertor target or limiter surface
Peak power flux on the divertor target or limiter surface
local/limiter/power_flux_peak/value(:) ⇹W.m^-2FLT_1DValue
Value
local/limiter/power_flux_peak/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/divertor_target(i1)AoSParameters at a divertor target
Parameters at a divertor target
Changed in version 3.35.0: Renamed from divertor_plate
local/divertor_target(i1)/namestructureName of the limiter or divertor plate. […] (click to expand)
Name of the limiter or divertor plate. Standard names are : LI (resp. LO) for lower inner (resp. outer) plates; UI (resp. UO) for upper inner (resp. outer) plates.
local/divertor_target(i1)/name/valueSTR_0DValue
Value
local/divertor_target(i1)/name/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/divertor_target(i1)/t_eeVstructureElectron temperature
Electron temperature
local/divertor_target(i1)/t_e/value(:) ⇹eVFLT_1DValue
Value
local/divertor_target(i1)/t_e/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/divertor_target(i1)/t_i_averageeVstructureIon temperature (average over ion species)
Ion temperature (average over ion species)
local/divertor_target(i1)/t_i_average/value(:) ⇹eVFLT_1DValue
Value
local/divertor_target(i1)/t_i_average/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/divertor_target(i1)/n_em^-3structureElectron density
Electron density
local/divertor_target(i1)/n_e/value(:) ⇹m^-3FLT_1DValue
Value
local/divertor_target(i1)/n_e/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/divertor_target(i1)/n_im^-3structureIon density per species
Ion density per species
local/divertor_target(i1)/n_i/hydrogenstructureHydrogen (H)
Hydrogen (H)
local/divertor_target(i1)/n_i/hydrogen/value(:) ⇹m^-3FLT_1DValue
Value
local/divertor_target(i1)/n_i/hydrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/divertor_target(i1)/n_i/deuteriumstructureDeuterium (D)
Deuterium (D)
local/divertor_target(i1)/n_i/deuterium/value(:) ⇹m^-3FLT_1DValue
Value
local/divertor_target(i1)/n_i/deuterium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/divertor_target(i1)/n_i/tritiumstructureTritium (T)
Tritium (T)
local/divertor_target(i1)/n_i/tritium/value(:) ⇹m^-3FLT_1DValue
Value
local/divertor_target(i1)/n_i/tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/divertor_target(i1)/n_i/deuterium_tritiumstructureFictitious DT single species with mass 2.5, used in some simulations
Fictitious DT single species with mass 2.5, used in some simulations
local/divertor_target(i1)/n_i/deuterium_tritium/value(:) ⇹m^-3FLT_1DValue
Value
local/divertor_target(i1)/n_i/deuterium_tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/divertor_target(i1)/n_i/helium_3structureHelium isotope with 3 nucleons (3He)
Helium isotope with 3 nucleons (3He)
local/divertor_target(i1)/n_i/helium_3/value(:) ⇹m^-3FLT_1DValue
Value
local/divertor_target(i1)/n_i/helium_3/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/divertor_target(i1)/n_i/helium_4structureHelium isotope with 4 nucleons (4He)
Helium isotope with 4 nucleons (4He)
local/divertor_target(i1)/n_i/helium_4/value(:) ⇹m^-3FLT_1DValue
Value
local/divertor_target(i1)/n_i/helium_4/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/divertor_target(i1)/n_i/berylliumstructureBeryllium (Be)
Beryllium (Be)
local/divertor_target(i1)/n_i/beryllium/value(:) ⇹m^-3FLT_1DValue
Value
local/divertor_target(i1)/n_i/beryllium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/divertor_target(i1)/n_i/boronstructureBoron (B)
Boron (B)
local/divertor_target(i1)/n_i/boron/value(:) ⇹m^-3FLT_1DValue
Value
local/divertor_target(i1)/n_i/boron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/divertor_target(i1)/n_i/lithiumstructureLithium (Li)
Lithium (Li)
local/divertor_target(i1)/n_i/lithium/value(:) ⇹m^-3FLT_1DValue
Value
local/divertor_target(i1)/n_i/lithium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/divertor_target(i1)/n_i/carbonstructureCarbon (C)
Carbon (C)
local/divertor_target(i1)/n_i/carbon/value(:) ⇹m^-3FLT_1DValue
Value
local/divertor_target(i1)/n_i/carbon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/divertor_target(i1)/n_i/nitrogenstructureNitrogen (N)
Nitrogen (N)
local/divertor_target(i1)/n_i/nitrogen/value(:) ⇹m^-3FLT_1DValue
Value
local/divertor_target(i1)/n_i/nitrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/divertor_target(i1)/n_i/neonstructureNeon (Ne)
Neon (Ne)
local/divertor_target(i1)/n_i/neon/value(:) ⇹m^-3FLT_1DValue
Value
local/divertor_target(i1)/n_i/neon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/divertor_target(i1)/n_i/argonstructureArgon (Ar)
Argon (Ar)
local/divertor_target(i1)/n_i/argon/value(:) ⇹m^-3FLT_1DValue
Value
local/divertor_target(i1)/n_i/argon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/divertor_target(i1)/n_i/xenonstructureXenon (Xe)
Xenon (Xe)
local/divertor_target(i1)/n_i/xenon/value(:) ⇹m^-3FLT_1DValue
Value
local/divertor_target(i1)/n_i/xenon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/divertor_target(i1)/n_i/oxygenstructureOxygen (O)
Oxygen (O)
local/divertor_target(i1)/n_i/oxygen/value(:) ⇹m^-3FLT_1DValue
Value
local/divertor_target(i1)/n_i/oxygen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/divertor_target(i1)/n_i/tungstenstructureTungsten (W)
Tungsten (W)
local/divertor_target(i1)/n_i/tungsten/value(:) ⇹m^-3FLT_1DValue
Value
local/divertor_target(i1)/n_i/tungsten/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/divertor_target(i1)/n_i/ironstructureIron (Fe)
Iron (Fe)
local/divertor_target(i1)/n_i/iron/value(:) ⇹m^-3FLT_1DValue
Value
local/divertor_target(i1)/n_i/iron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/divertor_target(i1)/n_i/kryptonstructureKrypton (Kr)
Krypton (Kr)
local/divertor_target(i1)/n_i/krypton/value(:) ⇹m^-3FLT_1DValue
Value
local/divertor_target(i1)/n_i/krypton/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/divertor_target(i1)/n_i_totalm^-3structureTotal ion density (sum over species)
Total ion density (sum over species)
local/divertor_target(i1)/n_i_total/value(:) ⇹m^-3FLT_1DValue
Value
local/divertor_target(i1)/n_i_total/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/divertor_target(i1)/zeff1structureEffective charge
Effective charge
local/divertor_target(i1)/zeff/value(:) ⇹1FLT_1DValue
Value
local/divertor_target(i1)/zeff/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/divertor_target(i1)/flux_expansion1structureMagnetic flux expansion as defined by Stangeby : ratio between […] (click to expand)
Magnetic flux expansion as defined by Stangeby : ratio between the poloidal field at the midplane separatrix and the poloidal field at the strike-point see formula attached, where u means upstream (midplane separatrix) and t means at divertor target (downstream).
Click here for further documentation.
local/divertor_target(i1)/flux_expansion/value(:) ⇹1FLT_1DValue
Value
local/divertor_target(i1)/flux_expansion/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/divertor_target(i1)/power_flux_peakW.m^-2structurePeak power flux on the divertor target or limiter surface
Peak power flux on the divertor target or limiter surface
local/divertor_target(i1)/power_flux_peak/value(:) ⇹W.m^-2FLT_1DValue
Value
local/divertor_target(i1)/power_flux_peak/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/r_eff_norm_2_3structureParameters at r_eff_norm = 2/3, where r_eff_norm is the stellarator […] (click to expand)
Parameters at r_eff_norm = 2/3, where r_eff_norm is the stellarator effective minor radius normalized to its value at the last closed flux surface
local/r_eff_norm_2_3/effective_helical_ripple1structureEffective helical ripple for 1/nu neoclassical regime (see [Beidler, […] (click to expand)
Effective helical ripple for 1/nu neoclassical regime (see [Beidler, C. D., and W. N. G. Hitchon, 1994, Plasma Phys. Control. Fusion 35, 317])
local/r_eff_norm_2_3/effective_helical_ripple/value(:) ⇹1FLT_1DValue
Value
local/r_eff_norm_2_3/effective_helical_ripple/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/r_eff_norm_2_3/plateau_factor1structurePlateau factor, as defined in equation (25) of reference [Stroth […] (click to expand)
Plateau factor, as defined in equation (25) of reference [Stroth U. et al 1998 Plasma Phys. Control. Fusion 40 1551]
local/r_eff_norm_2_3/plateau_factor/value(:) ⇹1FLT_1DValue
Value
local/r_eff_norm_2_3/plateau_factor/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
local/r_eff_norm_2_3/iota1structureRotational transform (1/q)
Rotational transform (1/q)
local/r_eff_norm_2_3/iota/value(:) ⇹1FLT_1DValue
Value
local/r_eff_norm_2_3/iota/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
boundarystructureDescription of the plasma boundary
Description of the plasma boundary
boundary/typestructure0 (limiter), 1 (diverted), 11 (LSN), 12 (USN), 13 (DN), 14 (snowflake)
0 (limiter), 1 (diverted), 11 (LSN), 12 (USN), 13 (DN), 14 (snowflake)
boundary/type/value(:)INT_1DValue
Value
boundary/type/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
boundary/geometric_axis_rmstructureR position of the geometric axis (defined as (Rmax+Rmin) / 2 […] (click to expand)
R position of the geometric axis (defined as (Rmax+Rmin) / 2 of the boundary)
boundary/geometric_axis_r/value(:) ⇹mFLT_1DValue
Value
boundary/geometric_axis_r/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
boundary/geometric_axis_zmstructureZ position of the geometric axis (defined as (Zmax+Zmin) / 2 […] (click to expand)
Z position of the geometric axis (defined as (Zmax+Zmin) / 2 of the boundary)
boundary/geometric_axis_z/value(:) ⇹mFLT_1DValue
Value
boundary/geometric_axis_z/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
boundary/magnetic_axis_rmstructureR position of the magnetic axis
R position of the magnetic axis
boundary/magnetic_axis_r/value(:) ⇹mFLT_1DValue
Value
boundary/magnetic_axis_r/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
boundary/magnetic_axis_zmstructureZ position of the magnetic axis
Z position of the magnetic axis
boundary/magnetic_axis_z/value(:) ⇹mFLT_1DValue
Value
boundary/magnetic_axis_z/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
boundary/minor_radiusmstructureMinor radius of the plasma boundary (defined as (Rmax-Rmin) / […] (click to expand)
Minor radius of the plasma boundary (defined as (Rmax-Rmin) / 2 of the boundary)
boundary/minor_radius/value(:) ⇹mFLT_1DValue
Value
boundary/minor_radius/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
boundary/elongation1structureElongation of the plasma boundary
Elongation of the plasma boundary
boundary/elongation/value(:) ⇹1FLT_1DValue
Value
boundary/elongation/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
boundary/triangularity_upper1structureUpper triangularity of the plasma boundary
Upper triangularity of the plasma boundary
boundary/triangularity_upper/value(:) ⇹1FLT_1DValue
Value
boundary/triangularity_upper/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
boundary/triangularity_lower1structureLower triangularity of the plasma boundary
Lower triangularity of the plasma boundary
boundary/triangularity_lower/value(:) ⇹1FLT_1DValue
Value
boundary/triangularity_lower/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
boundary/strike_point_inner_rmstructureR position of the inner strike point
R position of the inner strike point
boundary/strike_point_inner_r/value(:) ⇹mFLT_1DValue
Value
boundary/strike_point_inner_r/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
boundary/strike_point_inner_zmstructureZ position of the inner strike point
Z position of the inner strike point
boundary/strike_point_inner_z/value(:) ⇹mFLT_1DValue
Value
boundary/strike_point_inner_z/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
boundary/strike_point_outer_rmstructureR position of the outer strike point
R position of the outer strike point
boundary/strike_point_outer_r/value(:) ⇹mFLT_1DValue
Value
boundary/strike_point_outer_r/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
boundary/strike_point_outer_zmstructureZ position of the outer strike point
Z position of the outer strike point
boundary/strike_point_outer_z/value(:) ⇹mFLT_1DValue
Value
boundary/strike_point_outer_z/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
boundary/strike_point_configurationstructureString describing the configuration of the strike points (constant, […] (click to expand)
String describing the configuration of the strike points (constant, may need to become dynamic when available)
boundary/strike_point_configuration/valueSTR_0DValue
Value
boundary/strike_point_configuration/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
boundary/gap_limiter_wallmstructureDistance between the separatrix and the nearest limiter or wall […] (click to expand)
Distance between the separatrix and the nearest limiter or wall element
boundary/gap_limiter_wall/value(:) ⇹mFLT_1DValue
Value
boundary/gap_limiter_wall/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
boundary/distance_inner_outer_separatricesmstructureDistance between the inner and outer separatrices, in the major […] (click to expand)
Distance between the inner and outer separatrices, in the major radius direction, at the plasma outboard and at the height corresponding to the maximum R for the inner separatrix.
boundary/distance_inner_outer_separatrices/value(:) ⇹mFLT_1DValue
Value
boundary/distance_inner_outer_separatrices/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
boundary/x_point_mainstructureRZ position of the main X-point
RZ position of the main X-point
boundary/x_point_main/r(:) ⇹mFLT_1DMajor radius
Major radius
boundary/x_point_main/z(:) ⇹mFLT_1DHeight
Height
boundary/x_point_main/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fitsstructureQuantities derived from specific fits of pedestal profiles, typically […] (click to expand)
Quantities derived from specific fits of pedestal profiles, typically used in the Pedestal Database.
Click here for further documentation.
pedestal_fits/mtanhstructureQuantities related to “mtanh” fit
Quantities related to “mtanh” fit
pedestal_fits/mtanh/n_em^-3structureElectron density related quantities
Electron density related quantities
pedestal_fits/mtanh/n_e/separatrixstructureValue at separatrix
Value at separatrix
pedestal_fits/mtanh/n_e/separatrix/value(:) ⇹m^-3FLT_1DValue
Value
pedestal_fits/mtanh/n_e/separatrix/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/n_e/pedestal_heightstructurePedestal height
Pedestal height
pedestal_fits/mtanh/n_e/pedestal_height/value(:) ⇹m^-3FLT_1DValue
Value
pedestal_fits/mtanh/n_e/pedestal_height/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/n_e/pedestal_width1structurePedestal full width in normalized poloidal flux
Pedestal full width in normalized poloidal flux
pedestal_fits/mtanh/n_e/pedestal_width/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/mtanh/n_e/pedestal_width/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/n_e/pedestal_position1structurePedestal position in normalized poloidal flux
Pedestal position in normalized poloidal flux
pedestal_fits/mtanh/n_e/pedestal_position/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/mtanh/n_e/pedestal_position/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/n_e/offsetstructureOffset of the parent quantity in the SOL
Offset of the parent quantity in the SOL
pedestal_fits/mtanh/n_e/offset/value(:) ⇹m^-3FLT_1DValue
Value
pedestal_fits/mtanh/n_e/offset/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/n_e/d_dpsi_normstructureCore slope of the parent quantity
Core slope of the parent quantity
pedestal_fits/mtanh/n_e/d_dpsi_norm/value(:) ⇹m^-3FLT_1DValue
Value
pedestal_fits/mtanh/n_e/d_dpsi_norm/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/n_e/d_dpsi_norm_maxstructureMaximum gradient of the parent quantity (with respect to the […] (click to expand)
Maximum gradient of the parent quantity (with respect to the normalized poloidal flux) in the pedestal
pedestal_fits/mtanh/n_e/d_dpsi_norm_max/value(:) ⇹m^-3FLT_1DValue
Value
pedestal_fits/mtanh/n_e/d_dpsi_norm_max/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/n_e/d_dpsi_norm_max_position1structurePosition (in terms of normalized poloidal flux) of the maximum […] (click to expand)
Position (in terms of normalized poloidal flux) of the maximum gradient of the parent quantity in the pedestal
pedestal_fits/mtanh/n_e/d_dpsi_norm_max_position/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/mtanh/n_e/d_dpsi_norm_max_position/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/t_eeVstructureElectron temperature related quantities
Electron temperature related quantities
pedestal_fits/mtanh/t_e/pedestal_heightstructurePedestal height
Pedestal height
pedestal_fits/mtanh/t_e/pedestal_height/value(:) ⇹eVFLT_1DValue
Value
pedestal_fits/mtanh/t_e/pedestal_height/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/t_e/pedestal_width1structurePedestal full width in normalized poloidal flux
Pedestal full width in normalized poloidal flux
pedestal_fits/mtanh/t_e/pedestal_width/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/mtanh/t_e/pedestal_width/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/t_e/pedestal_position1structurePedestal position in normalized poloidal flux
Pedestal position in normalized poloidal flux
pedestal_fits/mtanh/t_e/pedestal_position/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/mtanh/t_e/pedestal_position/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/t_e/offsetstructureOffset of the parent quantity in the SOL
Offset of the parent quantity in the SOL
pedestal_fits/mtanh/t_e/offset/value(:) ⇹eVFLT_1DValue
Value
pedestal_fits/mtanh/t_e/offset/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/t_e/d_dpsi_normstructureCore slope of the parent quantity
Core slope of the parent quantity
pedestal_fits/mtanh/t_e/d_dpsi_norm/value(:) ⇹eVFLT_1DValue
Value
pedestal_fits/mtanh/t_e/d_dpsi_norm/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/t_e/d_dpsi_norm_maxstructureMaximum gradient of the parent quantity (with respect to the […] (click to expand)
Maximum gradient of the parent quantity (with respect to the normalized poloidal flux) in the pedestal
pedestal_fits/mtanh/t_e/d_dpsi_norm_max/value(:) ⇹eVFLT_1DValue
Value
pedestal_fits/mtanh/t_e/d_dpsi_norm_max/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/t_e/d_dpsi_norm_max_position1structurePosition (in terms of normalized poloidal flux) of the maximum […] (click to expand)
Position (in terms of normalized poloidal flux) of the maximum gradient of the parent quantity in the pedestal
pedestal_fits/mtanh/t_e/d_dpsi_norm_max_position/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/mtanh/t_e/d_dpsi_norm_max_position/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/pressure_electronPastructureElectron pressure related quantities
Electron pressure related quantities
pedestal_fits/mtanh/pressure_electron/separatrixstructureValue at separatrix
Value at separatrix
pedestal_fits/mtanh/pressure_electron/separatrix/value(:) ⇹PaFLT_1DValue
Value
pedestal_fits/mtanh/pressure_electron/separatrix/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/pressure_electron/pedestal_heightstructurePedestal height
Pedestal height
pedestal_fits/mtanh/pressure_electron/pedestal_height/value(:) ⇹PaFLT_1DValue
Value
pedestal_fits/mtanh/pressure_electron/pedestal_height/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/pressure_electron/pedestal_width1structurePedestal full width in normalized poloidal flux
Pedestal full width in normalized poloidal flux
pedestal_fits/mtanh/pressure_electron/pedestal_width/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/mtanh/pressure_electron/pedestal_width/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/pressure_electron/pedestal_position1structurePedestal position in normalized poloidal flux
Pedestal position in normalized poloidal flux
pedestal_fits/mtanh/pressure_electron/pedestal_position/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/mtanh/pressure_electron/pedestal_position/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/pressure_electron/offsetstructureOffset of the parent quantity in the SOL
Offset of the parent quantity in the SOL
pedestal_fits/mtanh/pressure_electron/offset/value(:) ⇹PaFLT_1DValue
Value
pedestal_fits/mtanh/pressure_electron/offset/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/pressure_electron/d_dpsi_normstructureCore slope of the parent quantity
Core slope of the parent quantity
pedestal_fits/mtanh/pressure_electron/d_dpsi_norm/value(:) ⇹PaFLT_1DValue
Value
pedestal_fits/mtanh/pressure_electron/d_dpsi_norm/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/pressure_electron/d_dpsi_norm_maxstructureMaximum gradient of the parent quantity (with respect to the […] (click to expand)
Maximum gradient of the parent quantity (with respect to the normalized poloidal flux) in the pedestal
pedestal_fits/mtanh/pressure_electron/d_dpsi_norm_max/value(:) ⇹PaFLT_1DValue
Value
pedestal_fits/mtanh/pressure_electron/d_dpsi_norm_max/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/pressure_electron/d_dpsi_norm_max_position1structurePosition (in terms of normalized poloidal flux) of the maximum […] (click to expand)
Position (in terms of normalized poloidal flux) of the maximum gradient of the parent quantity in the pedestal
pedestal_fits/mtanh/pressure_electron/d_dpsi_norm_max_position/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/mtanh/pressure_electron/d_dpsi_norm_max_position/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/energy_thermal_pedestal_electronJstructurePedestal stored thermal energy for electrons
Pedestal stored thermal energy for electrons
pedestal_fits/mtanh/energy_thermal_pedestal_electron/value(:) ⇹JFLT_1DValue
Value
pedestal_fits/mtanh/energy_thermal_pedestal_electron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/energy_thermal_pedestal_ionJstructurePedestal stored thermal energy for ions
Pedestal stored thermal energy for ions
pedestal_fits/mtanh/energy_thermal_pedestal_ion/value(:) ⇹JFLT_1DValue
Value
pedestal_fits/mtanh/energy_thermal_pedestal_ion/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/volume_inside_pedestalm^3structurePlasma volume enclosed between the magnetic axis and the top […] (click to expand)
Plasma volume enclosed between the magnetic axis and the top of the pedestal
pedestal_fits/mtanh/volume_inside_pedestal/value(:) ⇹m^3FLT_1DValue
Value
pedestal_fits/mtanh/volume_inside_pedestal/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/alpha_electron_pedestal_max1structureMaximum value in the pedestal of the alpha parameter for electron […] (click to expand)
Maximum value in the pedestal of the alpha parameter for electron pressure (see [Miller PoP 5 (1998),973,Eq. 42])
pedestal_fits/mtanh/alpha_electron_pedestal_max/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/mtanh/alpha_electron_pedestal_max/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/alpha_electron_pedestal_max_position1structurePosition in normalized poloidal flux of the maximum value in […] (click to expand)
Position in normalized poloidal flux of the maximum value in the pedestal of the alpha parameter for electron pressure (see [Miller PoP 5 (1998),973,Eq. 42])
pedestal_fits/mtanh/alpha_electron_pedestal_max_position/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/mtanh/alpha_electron_pedestal_max_position/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/beta_pol_pedestal_top_electron_average1structurePoloidal beta at pressure pedestal top for electrons using the […] (click to expand)
Poloidal beta at pressure pedestal top for electrons using the flux surface average magnetic poloidal field
pedestal_fits/mtanh/beta_pol_pedestal_top_electron_average/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/mtanh/beta_pol_pedestal_top_electron_average/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/beta_pol_pedestal_top_electron_lfs1structurePoloidal beta at pedestal top for electrons using the low field […] (click to expand)
Poloidal beta at pedestal top for electrons using the low field side magnetic poloidal field
pedestal_fits/mtanh/beta_pol_pedestal_top_electron_lfs/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/mtanh/beta_pol_pedestal_top_electron_lfs/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/beta_pol_pedestal_top_electron_hfs1structurePoloidal beta at pressure pedestal top for electrons using the […] (click to expand)
Poloidal beta at pressure pedestal top for electrons using the high field side magnetic poloidal field
pedestal_fits/mtanh/beta_pol_pedestal_top_electron_hfs/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/mtanh/beta_pol_pedestal_top_electron_hfs/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/nustar_pedestal_top_electron1structureNormalized collisionality at pressure pedestal top for electrons
Normalized collisionality at pressure pedestal top for electrons
pedestal_fits/mtanh/nustar_pedestal_top_electron/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/mtanh/nustar_pedestal_top_electron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/rhostar_pedestal_top_electron_lfs1structureNormalized Larmor radius at pressure pedestal top for electrons […] (click to expand)
Normalized Larmor radius at pressure pedestal top for electrons using the low field side magnetic field (important for spherical tokamaks)
pedestal_fits/mtanh/rhostar_pedestal_top_electron_lfs/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/mtanh/rhostar_pedestal_top_electron_lfs/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/rhostar_pedestal_top_electron_hfs1structureNormalized Larmor radius at pressure pedestal top for electrons […] (click to expand)
Normalized Larmor radius at pressure pedestal top for electrons using the high field side magnetic field (important for spherical tokamaks)
pedestal_fits/mtanh/rhostar_pedestal_top_electron_hfs/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/mtanh/rhostar_pedestal_top_electron_hfs/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/rhostar_pedestal_top_electron_magnetic_axis1structureNormalized Larmor radius at pressure pedestal top for electrons […] (click to expand)
Normalized Larmor radius at pressure pedestal top for electrons using the magnetic field on the magnetic axis (definition used in most tokamak litterature)
pedestal_fits/mtanh/rhostar_pedestal_top_electron_magnetic_axis/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/mtanh/rhostar_pedestal_top_electron_magnetic_axis/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/b_field_pol_pedestal_top_averageTstructurePoloidal field calculated at the position of the pressure pedestal […] (click to expand)
Poloidal field calculated at the position of the pressure pedestal top (as determined by the fit) and averaged over the flux surface
pedestal_fits/mtanh/b_field_pol_pedestal_top_average/value(:) ⇹TFLT_1DValue
Value
pedestal_fits/mtanh/b_field_pol_pedestal_top_average/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/b_field_pol_pedestal_top_hfsTstructurePoloidal field calculated at the position of the pressure pedestal […] (click to expand)
Poloidal field calculated at the position of the pressure pedestal top (as determined by the fit) on the high field side
pedestal_fits/mtanh/b_field_pol_pedestal_top_hfs/value(:) ⇹TFLT_1DValue
Value
pedestal_fits/mtanh/b_field_pol_pedestal_top_hfs/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/b_field_pol_pedestal_top_lfsTstructurePoloidal field calculated at the position of the pressure pedestal […] (click to expand)
Poloidal field calculated at the position of the pressure pedestal top (as determined by the fit) on the low field side
pedestal_fits/mtanh/b_field_pol_pedestal_top_lfs/value(:) ⇹TFLT_1DValue
Value
pedestal_fits/mtanh/b_field_pol_pedestal_top_lfs/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/b_field_pedestal_top_hfsTstructureTotal magnetic field calculated at the position of the pressure […] (click to expand)
Total magnetic field calculated at the position of the pressure pedestal top (as determined by the fit) on the high field side
pedestal_fits/mtanh/b_field_pedestal_top_hfs/value(:) ⇹TFLT_1DValue
Value
pedestal_fits/mtanh/b_field_pedestal_top_hfs/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/b_field_pedestal_top_lfsTstructureTotal magnetic field calculated at the position of the pressure […] (click to expand)
Total magnetic field calculated at the position of the pressure pedestal top (as determined by the fit) on the low field side
pedestal_fits/mtanh/b_field_pedestal_top_lfs/value(:) ⇹TFLT_1DValue
Value
pedestal_fits/mtanh/b_field_pedestal_top_lfs/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/b_field_tor_pedestal_top_hfsTstructureToroidal field calculated at the position of the pressure pedestal […] (click to expand)
Toroidal field calculated at the position of the pressure pedestal top (as determined by the fit) on the high field side
pedestal_fits/mtanh/b_field_tor_pedestal_top_hfs/value(:) ⇹TFLT_1DValue
Value
pedestal_fits/mtanh/b_field_tor_pedestal_top_hfs/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/b_field_tor_pedestal_top_lfsTstructureToroidal field calculated at the position of the pressure pedestal […] (click to expand)
Toroidal field calculated at the position of the pressure pedestal top (as determined by the fit) on the low field side
pedestal_fits/mtanh/b_field_tor_pedestal_top_lfs/value(:) ⇹TFLT_1DValue
Value
pedestal_fits/mtanh/b_field_tor_pedestal_top_lfs/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/coulomb_factor_pedestal_top1structureCoulomb factor log(lambda) at the position of the pressure pedestal […] (click to expand)
Coulomb factor log(lambda) at the position of the pressure pedestal top (as determined by the fit)
pedestal_fits/mtanh/coulomb_factor_pedestal_top/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/mtanh/coulomb_factor_pedestal_top/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/stabilitystructureMHD stability analysis of the pedestal (for this fit of the profiles)
MHD stability analysis of the pedestal (for this fit of the profiles)
pedestal_fits/mtanh/stability/alpha_experimental1structureExperimental normalized pressure gradient reconstructed by an […] (click to expand)
Experimental normalized pressure gradient reconstructed by an MHD stability code (with assumptions on the ion pressure). See definition in [Miller PoP 5 (1998),973,Eq. 42]
pedestal_fits/mtanh/stability/alpha_experimental/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/mtanh/stability/alpha_experimental/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/stability/bootstrap_current_sauterstructureMHD calculations of the critical alpha parameter using the Sauter […] (click to expand)
MHD calculations of the critical alpha parameter using the Sauter formula for the calculation of the bootstrap current, from Phys. Plasmas 6 (1999) 2834
pedestal_fits/mtanh/stability/bootstrap_current_sauter/alpha_critical1structureCritical normalized pressure gradient determined with self-consistent […] (click to expand)
Critical normalized pressure gradient determined with self-consistent runs with an MHD stability code. Details of the method for scanning parameters in the series of runs must be described in the ‘source’ node
pedestal_fits/mtanh/stability/bootstrap_current_sauter/alpha_critical/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/mtanh/stability/bootstrap_current_sauter/alpha_critical/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/stability/bootstrap_current_sauter/alpha_ratio1structureRatio of alpha_critical over alpha_experimental
Ratio of alpha_critical over alpha_experimental
pedestal_fits/mtanh/stability/bootstrap_current_sauter/alpha_ratio/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/mtanh/stability/bootstrap_current_sauter/alpha_ratio/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/stability/bootstrap_current_sauter/t_e_pedestal_top_criticaleVstructureCritical electron temperature at pedestal top determined with […] (click to expand)
Critical electron temperature at pedestal top determined with self-consistent runs with an MHD stability code. Details of the method for scanning parameters in the series of runs must be described in the ‘source’ node
pedestal_fits/mtanh/stability/bootstrap_current_sauter/t_e_pedestal_top_critical/value(:) ⇹eVFLT_1DValue
Value
pedestal_fits/mtanh/stability/bootstrap_current_sauter/t_e_pedestal_top_critical/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/stability/bootstrap_current_hagerstructureMHD calculations of the critical alpha parameter using the Hager […] (click to expand)
MHD calculations of the critical alpha parameter using the Hager formula for the calculation of the bootstrap current, from Phys. Plasmas 23 (2016) 042503
pedestal_fits/mtanh/stability/bootstrap_current_hager/alpha_critical1structureCritical normalized pressure gradient determined with self-consistent […] (click to expand)
Critical normalized pressure gradient determined with self-consistent runs with an MHD stability code. Details of the method for scanning parameters in the series of runs must be described in the ‘source’ node
pedestal_fits/mtanh/stability/bootstrap_current_hager/alpha_critical/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/mtanh/stability/bootstrap_current_hager/alpha_critical/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/stability/bootstrap_current_hager/alpha_ratio1structureRatio of alpha_critical over alpha_experimental
Ratio of alpha_critical over alpha_experimental
pedestal_fits/mtanh/stability/bootstrap_current_hager/alpha_ratio/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/mtanh/stability/bootstrap_current_hager/alpha_ratio/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/stability/bootstrap_current_hager/t_e_pedestal_top_criticaleVstructureCritical electron temperature at pedestal top determined with […] (click to expand)
Critical electron temperature at pedestal top determined with self-consistent runs with an MHD stability code. Details of the method for scanning parameters in the series of runs must be described in the ‘source’ node
pedestal_fits/mtanh/stability/bootstrap_current_hager/t_e_pedestal_top_critical/value(:) ⇹eVFLT_1DValue
Value
pedestal_fits/mtanh/stability/bootstrap_current_hager/t_e_pedestal_top_critical/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/mtanh/parameters(:) ⇹mixedFLT_1DParameters of the fit
Parameters of the fit
pedestal_fits/linearstructureQuantities related to linear fit
Quantities related to linear fit
pedestal_fits/linear/n_em^-3structureElectron density related quantities
Electron density related quantities
pedestal_fits/linear/n_e/separatrixstructureValue at separatrix
Value at separatrix
pedestal_fits/linear/n_e/separatrix/value(:) ⇹m^-3FLT_1DValue
Value
pedestal_fits/linear/n_e/separatrix/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/n_e/pedestal_heightstructurePedestal height
Pedestal height
pedestal_fits/linear/n_e/pedestal_height/value(:) ⇹m^-3FLT_1DValue
Value
pedestal_fits/linear/n_e/pedestal_height/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/n_e/pedestal_width1structurePedestal full width in normalized poloidal flux
Pedestal full width in normalized poloidal flux
pedestal_fits/linear/n_e/pedestal_width/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/linear/n_e/pedestal_width/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/n_e/pedestal_position1structurePedestal position in normalized poloidal flux
Pedestal position in normalized poloidal flux
pedestal_fits/linear/n_e/pedestal_position/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/linear/n_e/pedestal_position/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/n_e/offsetstructureOffset of the parent quantity in the SOL
Offset of the parent quantity in the SOL
pedestal_fits/linear/n_e/offset/value(:) ⇹m^-3FLT_1DValue
Value
pedestal_fits/linear/n_e/offset/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/n_e/d_dpsi_normstructureCore slope of the parent quantity
Core slope of the parent quantity
pedestal_fits/linear/n_e/d_dpsi_norm/value(:) ⇹m^-3FLT_1DValue
Value
pedestal_fits/linear/n_e/d_dpsi_norm/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/n_e/d_dpsi_norm_maxstructureMaximum gradient of the parent quantity (with respect to the […] (click to expand)
Maximum gradient of the parent quantity (with respect to the normalized poloidal flux) in the pedestal
pedestal_fits/linear/n_e/d_dpsi_norm_max/value(:) ⇹m^-3FLT_1DValue
Value
pedestal_fits/linear/n_e/d_dpsi_norm_max/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/t_eeVstructureElectron temperature related quantities
Electron temperature related quantities
pedestal_fits/linear/t_e/pedestal_heightstructurePedestal height
Pedestal height
pedestal_fits/linear/t_e/pedestal_height/value(:) ⇹eVFLT_1DValue
Value
pedestal_fits/linear/t_e/pedestal_height/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/t_e/pedestal_width1structurePedestal full width in normalized poloidal flux
Pedestal full width in normalized poloidal flux
pedestal_fits/linear/t_e/pedestal_width/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/linear/t_e/pedestal_width/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/t_e/pedestal_position1structurePedestal position in normalized poloidal flux
Pedestal position in normalized poloidal flux
pedestal_fits/linear/t_e/pedestal_position/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/linear/t_e/pedestal_position/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/t_e/offsetstructureOffset of the parent quantity in the SOL
Offset of the parent quantity in the SOL
pedestal_fits/linear/t_e/offset/value(:) ⇹eVFLT_1DValue
Value
pedestal_fits/linear/t_e/offset/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/t_e/d_dpsi_normstructureCore slope of the parent quantity
Core slope of the parent quantity
pedestal_fits/linear/t_e/d_dpsi_norm/value(:) ⇹eVFLT_1DValue
Value
pedestal_fits/linear/t_e/d_dpsi_norm/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/t_e/d_dpsi_norm_maxstructureMaximum gradient of the parent quantity (with respect to the […] (click to expand)
Maximum gradient of the parent quantity (with respect to the normalized poloidal flux) in the pedestal
pedestal_fits/linear/t_e/d_dpsi_norm_max/value(:) ⇹eVFLT_1DValue
Value
pedestal_fits/linear/t_e/d_dpsi_norm_max/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/pressure_electronPastructureElectron pressure related quantities
Electron pressure related quantities
pedestal_fits/linear/pressure_electron/separatrixstructureValue at separatrix
Value at separatrix
pedestal_fits/linear/pressure_electron/separatrix/value(:) ⇹PaFLT_1DValue
Value
pedestal_fits/linear/pressure_electron/separatrix/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/pressure_electron/pedestal_heightstructurePedestal height
Pedestal height
pedestal_fits/linear/pressure_electron/pedestal_height/value(:) ⇹PaFLT_1DValue
Value
pedestal_fits/linear/pressure_electron/pedestal_height/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/pressure_electron/pedestal_width1structurePedestal full width in normalized poloidal flux
Pedestal full width in normalized poloidal flux
pedestal_fits/linear/pressure_electron/pedestal_width/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/linear/pressure_electron/pedestal_width/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/pressure_electron/pedestal_position1structurePedestal position in normalized poloidal flux
Pedestal position in normalized poloidal flux
pedestal_fits/linear/pressure_electron/pedestal_position/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/linear/pressure_electron/pedestal_position/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/pressure_electron/offsetstructureOffset of the parent quantity in the SOL
Offset of the parent quantity in the SOL
pedestal_fits/linear/pressure_electron/offset/value(:) ⇹PaFLT_1DValue
Value
pedestal_fits/linear/pressure_electron/offset/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/pressure_electron/d_dpsi_normstructureCore slope of the parent quantity
Core slope of the parent quantity
pedestal_fits/linear/pressure_electron/d_dpsi_norm/value(:) ⇹PaFLT_1DValue
Value
pedestal_fits/linear/pressure_electron/d_dpsi_norm/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/pressure_electron/d_dpsi_norm_maxstructureMaximum gradient of the parent quantity (with respect to the […] (click to expand)
Maximum gradient of the parent quantity (with respect to the normalized poloidal flux) in the pedestal
pedestal_fits/linear/pressure_electron/d_dpsi_norm_max/value(:) ⇹PaFLT_1DValue
Value
pedestal_fits/linear/pressure_electron/d_dpsi_norm_max/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/pressure_electron/d_dpsi_norm_max_position1structurePosition (in terms of normalized poloidal flux) of the maximum […] (click to expand)
Position (in terms of normalized poloidal flux) of the maximum gradient of the parent quantity in the pedestal
pedestal_fits/linear/pressure_electron/d_dpsi_norm_max_position/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/linear/pressure_electron/d_dpsi_norm_max_position/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/energy_thermal_pedestal_electronJstructurePedestal stored thermal energy for electrons
Pedestal stored thermal energy for electrons
pedestal_fits/linear/energy_thermal_pedestal_electron/value(:) ⇹JFLT_1DValue
Value
pedestal_fits/linear/energy_thermal_pedestal_electron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/energy_thermal_pedestal_ionJstructurePedestal stored thermal energy for ions
Pedestal stored thermal energy for ions
pedestal_fits/linear/energy_thermal_pedestal_ion/value(:) ⇹JFLT_1DValue
Value
pedestal_fits/linear/energy_thermal_pedestal_ion/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/volume_inside_pedestalm^3structurePlasma volume enclosed between the magnetic axis and the top […] (click to expand)
Plasma volume enclosed between the magnetic axis and the top of the pedestal
pedestal_fits/linear/volume_inside_pedestal/value(:) ⇹m^3FLT_1DValue
Value
pedestal_fits/linear/volume_inside_pedestal/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/beta_pol_pedestal_top_electron_average1structurePoloidal beta at pressure pedestal top for electrons using the […] (click to expand)
Poloidal beta at pressure pedestal top for electrons using the flux surface average magnetic poloidal field
pedestal_fits/linear/beta_pol_pedestal_top_electron_average/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/linear/beta_pol_pedestal_top_electron_average/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/beta_pol_pedestal_top_electron_lfs1structurePoloidal beta at pressure pedestal top for electrons using the […] (click to expand)
Poloidal beta at pressure pedestal top for electrons using the low field side magnetic poloidal field
pedestal_fits/linear/beta_pol_pedestal_top_electron_lfs/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/linear/beta_pol_pedestal_top_electron_lfs/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/beta_pol_pedestal_top_electron_hfs1structurePoloidal beta at pressure pedestal top for electrons using the […] (click to expand)
Poloidal beta at pressure pedestal top for electrons using the high field side magnetic poloidal field
pedestal_fits/linear/beta_pol_pedestal_top_electron_hfs/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/linear/beta_pol_pedestal_top_electron_hfs/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/nustar_pedestal_top_electron1structureNormalized collisionality at pressure pedestal top for electrons
Normalized collisionality at pressure pedestal top for electrons
pedestal_fits/linear/nustar_pedestal_top_electron/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/linear/nustar_pedestal_top_electron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/rhostar_pedestal_top_electron_lfs1structureNormalized Larmor radius at pressure pedestal top for electrons […] (click to expand)
Normalized Larmor radius at pressure pedestal top for electrons using the low field side magnetic field (important for spherical tokamaks)
pedestal_fits/linear/rhostar_pedestal_top_electron_lfs/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/linear/rhostar_pedestal_top_electron_lfs/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/rhostar_pedestal_top_electron_hfs1structureNormalized Larmor radius at pressure pedestal top for electrons […] (click to expand)
Normalized Larmor radius at pressure pedestal top for electrons using the high field side magnetic field (important for spherical tokamaks)
pedestal_fits/linear/rhostar_pedestal_top_electron_hfs/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/linear/rhostar_pedestal_top_electron_hfs/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/rhostar_pedestal_top_electron_magnetic_axis1structureNormalized Larmor radius at pressure pedestal top for electrons […] (click to expand)
Normalized Larmor radius at pressure pedestal top for electrons using the magnetic field on the magnetic axis (definition used in most tokamak literature)
pedestal_fits/linear/rhostar_pedestal_top_electron_magnetic_axis/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/linear/rhostar_pedestal_top_electron_magnetic_axis/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/b_field_pol_pedestal_top_averageTstructurePoloidal field calculated at the position of the pressure pedestal […] (click to expand)
Poloidal field calculated at the position of the pressure pedestal top (as determined by the fit) and averaged over the flux surface
pedestal_fits/linear/b_field_pol_pedestal_top_average/value(:) ⇹TFLT_1DValue
Value
pedestal_fits/linear/b_field_pol_pedestal_top_average/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/b_field_pol_pedestal_top_hfsTstructurePoloidal field calculated at the position of the pressure pedestal […] (click to expand)
Poloidal field calculated at the position of the pressure pedestal top (as determined by the fit) on the high field side
pedestal_fits/linear/b_field_pol_pedestal_top_hfs/value(:) ⇹TFLT_1DValue
Value
pedestal_fits/linear/b_field_pol_pedestal_top_hfs/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/b_field_pol_pedestal_top_lfsTstructurePoloidal field calculated at the position of the pressure pedestal […] (click to expand)
Poloidal field calculated at the position of the pressure pedestal top (as determined by the fit) on the low field side
pedestal_fits/linear/b_field_pol_pedestal_top_lfs/value(:) ⇹TFLT_1DValue
Value
pedestal_fits/linear/b_field_pol_pedestal_top_lfs/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/b_field_pedestal_top_hfsTstructureTotal magnetic field calculated at the position of the pressure […] (click to expand)
Total magnetic field calculated at the position of the pressure pedestal top (as determined by the fit) on the high field side
pedestal_fits/linear/b_field_pedestal_top_hfs/value(:) ⇹TFLT_1DValue
Value
pedestal_fits/linear/b_field_pedestal_top_hfs/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/b_field_pedestal_top_lfsTstructureTotal magnetic field calculated at the position of the pressure […] (click to expand)
Total magnetic field calculated at the position of the pressure pedestal top (as determined by the fit) on the low field side
pedestal_fits/linear/b_field_pedestal_top_lfs/value(:) ⇹TFLT_1DValue
Value
pedestal_fits/linear/b_field_pedestal_top_lfs/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/b_field_tor_pedestal_top_hfsTstructureToroidal field calculated at the position of the pressure pedestal […] (click to expand)
Toroidal field calculated at the position of the pressure pedestal top (as determined by the fit) on the high field side
pedestal_fits/linear/b_field_tor_pedestal_top_hfs/value(:) ⇹TFLT_1DValue
Value
pedestal_fits/linear/b_field_tor_pedestal_top_hfs/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/b_field_tor_pedestal_top_lfsTstructureToroidal field calculated at the position of the pressure pedestal […] (click to expand)
Toroidal field calculated at the position of the pressure pedestal top (as determined by the fit) on the low field side
pedestal_fits/linear/b_field_tor_pedestal_top_lfs/value(:) ⇹TFLT_1DValue
Value
pedestal_fits/linear/b_field_tor_pedestal_top_lfs/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/coulomb_factor_pedestal_top1structureCoulomb factor log(lambda) at the position of the pressure pedestal […] (click to expand)
Coulomb factor log(lambda) at the position of the pressure pedestal top (as determined by the fit)
pedestal_fits/linear/coulomb_factor_pedestal_top/value(:) ⇹1FLT_1DValue
Value
pedestal_fits/linear/coulomb_factor_pedestal_top/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pedestal_fits/linear/parameters(:) ⇹mixedFLT_1DParameters of the fit
Parameters of the fit
line_averagestructureLine average plasma parameters
Line average plasma parameters
line_average/t_eeVstructureElectron temperature
Electron temperature
line_average/t_e/value(:) ⇹eVFLT_1DValue
Value
line_average/t_e/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
line_average/t_i_averageeVstructureIon temperature (average over ion species)
Ion temperature (average over ion species)
line_average/t_i_average/value(:) ⇹eVFLT_1DValue
Value
line_average/t_i_average/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
line_average/n_em^-3structureElectron density
Electron density
line_average/n_e/value(:) ⇹m^-3FLT_1DValue
Value
line_average/n_e/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
line_average/dn_e_dtm^-3.s^-1structureTime derivative of the electron density
Time derivative of the electron density
line_average/dn_e_dt/value(:) ⇹m^-3.s^-1FLT_1DValue
Value
line_average/dn_e_dt/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
line_average/n_im^-3structureIon density per species
Ion density per species
line_average/n_i/hydrogenstructureHydrogen (H)
Hydrogen (H)
line_average/n_i/hydrogen/value(:) ⇹m^-3FLT_1DValue
Value
line_average/n_i/hydrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
line_average/n_i/deuteriumstructureDeuterium (D)
Deuterium (D)
line_average/n_i/deuterium/value(:) ⇹m^-3FLT_1DValue
Value
line_average/n_i/deuterium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
line_average/n_i/tritiumstructureTritium (T)
Tritium (T)
line_average/n_i/tritium/value(:) ⇹m^-3FLT_1DValue
Value
line_average/n_i/tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
line_average/n_i/deuterium_tritiumstructureFictitious DT single species with mass 2.5, used in some simulations
Fictitious DT single species with mass 2.5, used in some simulations
line_average/n_i/deuterium_tritium/value(:) ⇹m^-3FLT_1DValue
Value
line_average/n_i/deuterium_tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
line_average/n_i/helium_3structureHelium isotope with 3 nucleons (3He)
Helium isotope with 3 nucleons (3He)
line_average/n_i/helium_3/value(:) ⇹m^-3FLT_1DValue
Value
line_average/n_i/helium_3/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
line_average/n_i/helium_4structureHelium isotope with 4 nucleons (4He)
Helium isotope with 4 nucleons (4He)
line_average/n_i/helium_4/value(:) ⇹m^-3FLT_1DValue
Value
line_average/n_i/helium_4/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
line_average/n_i/berylliumstructureBeryllium (Be)
Beryllium (Be)
line_average/n_i/beryllium/value(:) ⇹m^-3FLT_1DValue
Value
line_average/n_i/beryllium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
line_average/n_i/boronstructureBoron (B)
Boron (B)
line_average/n_i/boron/value(:) ⇹m^-3FLT_1DValue
Value
line_average/n_i/boron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
line_average/n_i/lithiumstructureLithium (Li)
Lithium (Li)
line_average/n_i/lithium/value(:) ⇹m^-3FLT_1DValue
Value
line_average/n_i/lithium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
line_average/n_i/carbonstructureCarbon (C)
Carbon (C)
line_average/n_i/carbon/value(:) ⇹m^-3FLT_1DValue
Value
line_average/n_i/carbon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
line_average/n_i/nitrogenstructureNitrogen (N)
Nitrogen (N)
line_average/n_i/nitrogen/value(:) ⇹m^-3FLT_1DValue
Value
line_average/n_i/nitrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
line_average/n_i/neonstructureNeon (Ne)
Neon (Ne)
line_average/n_i/neon/value(:) ⇹m^-3FLT_1DValue
Value
line_average/n_i/neon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
line_average/n_i/argonstructureArgon (Ar)
Argon (Ar)
line_average/n_i/argon/value(:) ⇹m^-3FLT_1DValue
Value
line_average/n_i/argon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
line_average/n_i/xenonstructureXenon (Xe)
Xenon (Xe)
line_average/n_i/xenon/value(:) ⇹m^-3FLT_1DValue
Value
line_average/n_i/xenon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
line_average/n_i/oxygenstructureOxygen (O)
Oxygen (O)
line_average/n_i/oxygen/value(:) ⇹m^-3FLT_1DValue
Value
line_average/n_i/oxygen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
line_average/n_i/tungstenstructureTungsten (W)
Tungsten (W)
line_average/n_i/tungsten/value(:) ⇹m^-3FLT_1DValue
Value
line_average/n_i/tungsten/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
line_average/n_i/ironstructureIron (Fe)
Iron (Fe)
line_average/n_i/iron/value(:) ⇹m^-3FLT_1DValue
Value
line_average/n_i/iron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
line_average/n_i/kryptonstructureKrypton (Kr)
Krypton (Kr)
line_average/n_i/krypton/value(:) ⇹m^-3FLT_1DValue
Value
line_average/n_i/krypton/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
line_average/n_i_totalm^-3structureTotal ion density (sum over species)
Total ion density (sum over species)
line_average/n_i_total/value(:) ⇹m^-3FLT_1DValue
Value
line_average/n_i_total/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
line_average/zeff1structureEffective charge
Effective charge
line_average/zeff/value(:) ⇹1FLT_1DValue
Value
line_average/zeff/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
line_average/meff_hydrogenicustructureEffective mass of the hydrogenic species (MH. […] (click to expand)
Effective mass of the hydrogenic species (MH. nH+MD.nD+MT.nT)/(nH+nD+nT)
line_average/meff_hydrogenic/value(:) ⇹uFLT_1DValue
Value
line_average/meff_hydrogenic/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
line_average/isotope_fraction_hydrogen1structureFraction of hydrogen density among the hydrogenic species (nH/(nH+nD+nT))
Fraction of hydrogen density among the hydrogenic species (nH/(nH+nD+nT))
line_average/isotope_fraction_hydrogen/value(:) ⇹1FLT_1DValue
Value
line_average/isotope_fraction_hydrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
volume_averagestructureVolume-averaged plasma parameters (averaged over the confined […] (click to expand)
Volume-averaged plasma parameters (averaged over the confined plasma volume, i.e. inside the LCFS)
volume_average/t_eeVstructureElectron temperature
Electron temperature
volume_average/t_e/value(:) ⇹eVFLT_1DValue
Value
volume_average/t_e/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
volume_average/t_i_averageeVstructureIon temperature (average over ion species)
Ion temperature (average over ion species)
volume_average/t_i_average/value(:) ⇹eVFLT_1DValue
Value
volume_average/t_i_average/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
volume_average/n_em^-3structureElectron density
Electron density
volume_average/n_e/value(:) ⇹m^-3FLT_1DValue
Value
volume_average/n_e/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
volume_average/dn_e_dtm^-3.s^-1structureTime derivative of the electron density
Time derivative of the electron density
volume_average/dn_e_dt/value(:) ⇹m^-3.s^-1FLT_1DValue
Value
volume_average/dn_e_dt/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
volume_average/n_im^-3structureIon density per species
Ion density per species
volume_average/n_i/hydrogenstructureHydrogen (H)
Hydrogen (H)
volume_average/n_i/hydrogen/value(:) ⇹m^-3FLT_1DValue
Value
volume_average/n_i/hydrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
volume_average/n_i/deuteriumstructureDeuterium (D)
Deuterium (D)
volume_average/n_i/deuterium/value(:) ⇹m^-3FLT_1DValue
Value
volume_average/n_i/deuterium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
volume_average/n_i/tritiumstructureTritium (T)
Tritium (T)
volume_average/n_i/tritium/value(:) ⇹m^-3FLT_1DValue
Value
volume_average/n_i/tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
volume_average/n_i/deuterium_tritiumstructureFictitious DT single species with mass 2.5, used in some simulations
Fictitious DT single species with mass 2.5, used in some simulations
volume_average/n_i/deuterium_tritium/value(:) ⇹m^-3FLT_1DValue
Value
volume_average/n_i/deuterium_tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
volume_average/n_i/helium_3structureHelium isotope with 3 nucleons (3He)
Helium isotope with 3 nucleons (3He)
volume_average/n_i/helium_3/value(:) ⇹m^-3FLT_1DValue
Value
volume_average/n_i/helium_3/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
volume_average/n_i/helium_4structureHelium isotope with 4 nucleons (4He)
Helium isotope with 4 nucleons (4He)
volume_average/n_i/helium_4/value(:) ⇹m^-3FLT_1DValue
Value
volume_average/n_i/helium_4/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
volume_average/n_i/berylliumstructureBeryllium (Be)
Beryllium (Be)
volume_average/n_i/beryllium/value(:) ⇹m^-3FLT_1DValue
Value
volume_average/n_i/beryllium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
volume_average/n_i/boronstructureBoron (B)
Boron (B)
volume_average/n_i/boron/value(:) ⇹m^-3FLT_1DValue
Value
volume_average/n_i/boron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
volume_average/n_i/lithiumstructureLithium (Li)
Lithium (Li)
volume_average/n_i/lithium/value(:) ⇹m^-3FLT_1DValue
Value
volume_average/n_i/lithium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
volume_average/n_i/carbonstructureCarbon (C)
Carbon (C)
volume_average/n_i/carbon/value(:) ⇹m^-3FLT_1DValue
Value
volume_average/n_i/carbon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
volume_average/n_i/nitrogenstructureNitrogen (N)
Nitrogen (N)
volume_average/n_i/nitrogen/value(:) ⇹m^-3FLT_1DValue
Value
volume_average/n_i/nitrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
volume_average/n_i/neonstructureNeon (Ne)
Neon (Ne)
volume_average/n_i/neon/value(:) ⇹m^-3FLT_1DValue
Value
volume_average/n_i/neon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
volume_average/n_i/argonstructureArgon (Ar)
Argon (Ar)
volume_average/n_i/argon/value(:) ⇹m^-3FLT_1DValue
Value
volume_average/n_i/argon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
volume_average/n_i/xenonstructureXenon (Xe)
Xenon (Xe)
volume_average/n_i/xenon/value(:) ⇹m^-3FLT_1DValue
Value
volume_average/n_i/xenon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
volume_average/n_i/oxygenstructureOxygen (O)
Oxygen (O)
volume_average/n_i/oxygen/value(:) ⇹m^-3FLT_1DValue
Value
volume_average/n_i/oxygen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
volume_average/n_i/tungstenstructureTungsten (W)
Tungsten (W)
volume_average/n_i/tungsten/value(:) ⇹m^-3FLT_1DValue
Value
volume_average/n_i/tungsten/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
volume_average/n_i/ironstructureIron (Fe)
Iron (Fe)
volume_average/n_i/iron/value(:) ⇹m^-3FLT_1DValue
Value
volume_average/n_i/iron/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
volume_average/n_i/kryptonstructureKrypton (Kr)
Krypton (Kr)
volume_average/n_i/krypton/value(:) ⇹m^-3FLT_1DValue
Value
volume_average/n_i/krypton/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
volume_average/n_i_totalm^-3structureTotal ion density (sum over species)
Total ion density (sum over species)
volume_average/n_i_total/value(:) ⇹m^-3FLT_1DValue
Value
volume_average/n_i_total/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
volume_average/zeff1structureEffective charge
Effective charge
volume_average/zeff/value(:) ⇹1FLT_1DValue
Value
volume_average/zeff/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
volume_average/meff_hydrogenicustructureEffective mass of the hydrogenic species (MH. […] (click to expand)
Effective mass of the hydrogenic species (MH. nH+MD.nD+MT.nT)/(nH+nD+nT)
volume_average/meff_hydrogenic/value(:) ⇹uFLT_1DValue
Value
volume_average/meff_hydrogenic/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
volume_average/isotope_fraction_hydrogen1structureFraction of hydrogen density among the hydrogenic species (nH/(nH+nD+nT))
Fraction of hydrogen density among the hydrogenic species (nH/(nH+nD+nT))
volume_average/isotope_fraction_hydrogen/value(:) ⇹1FLT_1DValue
Value
volume_average/isotope_fraction_hydrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
disruptionstructureDisruption characteristics, if the pulse is terminated by a disruption
Disruption characteristics, if the pulse is terminated by a disruption
disruption/timesstructureTime of the disruption = min(t_TQ, t_VDE), where t_TQ and t_VDE […] (click to expand)
Time of the disruption = min(t_TQ, t_VDE), where t_TQ and t_VDE are the times at which the Thermal Quench (TQ) and the Vertical Displacement Event (VDE) are detected by their respective detectors
disruption/time/value ⇹sFLT_0DValue
Value
disruption/time/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
disruption/time_predisruptionsstructurePre-disruption time = disruption.time - t_pre, where t_pre[s] […] (click to expand)
Pre-disruption time = disruption.time - t_pre, where t_pre[s] is approximately given by 0.0025 * R0[m]^2 and R0 is the major radius where the toroidal field is defined (../../global_quantities/r0)
disruption/time_predisruption/value ⇹sFLT_0DValue
Value
disruption/time_predisruption/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
disruption/time_radiated_power_maxsstructureTime of maximum radiated power, relative to the time of the disruption
Time of maximum radiated power, relative to the time of the disruption
disruption/time_radiated_power_max/value ⇹sFLT_0DValue
Value
disruption/time_radiated_power_max/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
disruption/time_half_ipsstructureTime at which the plasma current has fallen to half of the initial […] (click to expand)
Time at which the plasma current has fallen to half of the initial current at the start of the disruption, relative to the time of the disruption
disruption/time_half_ip/value ⇹sFLT_0DValue
Value
disruption/time_half_ip/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
disruption/vertical_displacementsstructureDirection of the plasma vertical displacement just before the […] (click to expand)
Direction of the plasma vertical displacement just before the disruption 1 (upwards) / 0 (no displacement)/ -1 (downwards)
disruption/vertical_displacement/valueINT_0DValue
Value
disruption/vertical_displacement/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
disruption/mitigation_valvestructureFlag indicating whether any disruption mitigation valve has been […] (click to expand)
Flag indicating whether any disruption mitigation valve has been used (1) or none (0)
disruption/mitigation_valve/valueINT_0DValue
Value
disruption/mitigation_valve/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
disruption/decay_timesstructureCharacteristic decay times describing the loss of different quantities […] (click to expand)
Characteristic decay times describing the loss of different quantities during the disruption
disruption/decay_times/ipstructureTotal toroidal plasma current (including runaway electrons and […] (click to expand)
Total toroidal plasma current (including runaway electrons and halo currents)
disruption/decay_times/ip/linear_20_80sstructureDecay time defined as (t(0.2)-t(0.8))/0.6, where t(X) corresponds […] (click to expand)
Decay time defined as (t(0.2)-t(0.8))/0.6, where t(X) corresponds to the time where this quantity reaches X*100% of its pre-disruptive value
disruption/decay_times/ip/linear_20_80/value ⇹sFLT_0DValue
Value
disruption/decay_times/ip/linear_20_80/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
disruption/decay_times/ip/linear_customstructureDecay time defined as (t(X2)-t(X1))/(X1-X2), where t(Xj) corresponds […] (click to expand)
Decay time defined as (t(X2)-t(X1))/(X1-X2), where t(Xj) corresponds to the time where this quantity reaches Xj*100% of its pre-disruptive value
disruption/decay_times/ip/linear_custom/x1 ⇹1FLT_0DUser-defined parameter, see description of linear_custom
User-defined parameter, see description of linear_custom
disruption/decay_times/ip/linear_custom/x2 ⇹1FLT_0DUser-defined value, see description of linear_custom
User-defined value, see description of linear_custom
disruption/decay_times/ip/linear_custom/decay_timesstructureDecay time
Decay time
disruption/decay_times/ip/linear_custom/decay_time/value ⇹sFLT_0DValue
Value
disruption/decay_times/ip/linear_custom/decay_time/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
disruption/decay_times/ip/exponentialsstructureExponential decay time (tau) used when the process is described […] (click to expand)
Exponential decay time (tau) used when the process is described by an exponential function (exp(-(t-t0)/tau))). Here “t” is time and “t0” is the time where the decay process starts
disruption/decay_times/ip/exponential/value ⇹sFLT_0DValue
Value
disruption/decay_times/ip/exponential/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
disruption/decay_times/current_runawaysstructureTotal toroidal current carried by runaway electrons
Total toroidal current carried by runaway electrons
disruption/decay_times/current_runaways/linear_20_80sstructureDecay time defined as (t(0.2)-t(0.8))/0.6, where t(X) corresponds […] (click to expand)
Decay time defined as (t(0.2)-t(0.8))/0.6, where t(X) corresponds to the time where this quantity reaches X*100% of its pre-disruptive value
disruption/decay_times/current_runaways/linear_20_80/value ⇹sFLT_0DValue
Value
disruption/decay_times/current_runaways/linear_20_80/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
disruption/decay_times/current_runaways/linear_customstructureDecay time defined as (t(X2)-t(X1))/(X1-X2), where t(Xj) corresponds […] (click to expand)
Decay time defined as (t(X2)-t(X1))/(X1-X2), where t(Xj) corresponds to the time where this quantity reaches Xj*100% of its pre-disruptive value
disruption/decay_times/current_runaways/linear_custom/x1 ⇹1FLT_0DUser-defined parameter, see description of linear_custom
User-defined parameter, see description of linear_custom
disruption/decay_times/current_runaways/linear_custom/x2 ⇹1FLT_0DUser-defined value, see description of linear_custom
User-defined value, see description of linear_custom
disruption/decay_times/current_runaways/linear_custom/decay_timesstructureDecay time
Decay time
disruption/decay_times/current_runaways/linear_custom/decay_time/value ⇹sFLT_0DValue
Value
disruption/decay_times/current_runaways/linear_custom/decay_time/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
disruption/decay_times/current_runaways/exponentialsstructureExponential decay time (tau) used when the process is described […] (click to expand)
Exponential decay time (tau) used when the process is described by an exponential function (exp(-(t-t0)/tau))). Here “t” is time and “t0” is the time where the decay process starts
disruption/decay_times/current_runaways/exponential/value ⇹sFLT_0DValue
Value
disruption/decay_times/current_runaways/exponential/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
disruption/decay_times/t_e_volume_averagestructureVolume average electron temperature
Volume average electron temperature
disruption/decay_times/t_e_volume_average/linear_20_80sstructureDecay time defined as (t(0.2)-t(0.8))/0.6, where t(X) corresponds […] (click to expand)
Decay time defined as (t(0.2)-t(0.8))/0.6, where t(X) corresponds to the time where this quantity reaches X*100% of its pre-disruptive value
disruption/decay_times/t_e_volume_average/linear_20_80/value ⇹sFLT_0DValue
Value
disruption/decay_times/t_e_volume_average/linear_20_80/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
disruption/decay_times/t_e_volume_average/linear_customstructureDecay time defined as (t(X2)-t(X1))/(X1-X2), where t(Xj) corresponds […] (click to expand)
Decay time defined as (t(X2)-t(X1))/(X1-X2), where t(Xj) corresponds to the time where this quantity reaches Xj*100% of its pre-disruptive value
disruption/decay_times/t_e_volume_average/linear_custom/x1 ⇹1FLT_0DUser-defined parameter, see description of linear_custom
User-defined parameter, see description of linear_custom
disruption/decay_times/t_e_volume_average/linear_custom/x2 ⇹1FLT_0DUser-defined value, see description of linear_custom
User-defined value, see description of linear_custom
disruption/decay_times/t_e_volume_average/linear_custom/decay_timesstructureDecay time
Decay time
disruption/decay_times/t_e_volume_average/linear_custom/decay_time/value ⇹sFLT_0DValue
Value
disruption/decay_times/t_e_volume_average/linear_custom/decay_time/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
disruption/decay_times/t_e_volume_average/exponentialsstructureExponential decay time (tau) used when the process is described […] (click to expand)
Exponential decay time (tau) used when the process is described by an exponential function (exp(-(t-t0)/tau))). Here “t” is time and “t0” is the time where the decay process starts
disruption/decay_times/t_e_volume_average/exponential/value ⇹sFLT_0DValue
Value
disruption/decay_times/t_e_volume_average/exponential/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
disruption/decay_times/t_e_magnetic_axisstructureElectron temperature at the magnetic axis
Electron temperature at the magnetic axis
disruption/decay_times/t_e_magnetic_axis/linear_20_80sstructureDecay time defined as (t(0.2)-t(0.8))/0.6, where t(X) corresponds […] (click to expand)
Decay time defined as (t(0.2)-t(0.8))/0.6, where t(X) corresponds to the time where this quantity reaches X*100% of its pre-disruptive value
disruption/decay_times/t_e_magnetic_axis/linear_20_80/value ⇹sFLT_0DValue
Value
disruption/decay_times/t_e_magnetic_axis/linear_20_80/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
disruption/decay_times/t_e_magnetic_axis/linear_customstructureDecay time defined as (t(X2)-t(X1))/(X1-X2), where t(Xj) corresponds […] (click to expand)
Decay time defined as (t(X2)-t(X1))/(X1-X2), where t(Xj) corresponds to the time where this quantity reaches Xj*100% of its pre-disruptive value
disruption/decay_times/t_e_magnetic_axis/linear_custom/x1 ⇹1FLT_0DUser-defined parameter, see description of linear_custom
User-defined parameter, see description of linear_custom
disruption/decay_times/t_e_magnetic_axis/linear_custom/x2 ⇹1FLT_0DUser-defined value, see description of linear_custom
User-defined value, see description of linear_custom
disruption/decay_times/t_e_magnetic_axis/linear_custom/decay_timesstructureDecay time
Decay time
disruption/decay_times/t_e_magnetic_axis/linear_custom/decay_time/value ⇹sFLT_0DValue
Value
disruption/decay_times/t_e_magnetic_axis/linear_custom/decay_time/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
disruption/decay_times/t_e_magnetic_axis/exponentialsstructureExponential decay time (tau) used when the process is described […] (click to expand)
Exponential decay time (tau) used when the process is described by an exponential function (exp(-(t-t0)/tau))). Here “t” is time and “t0” is the time where the decay process starts
disruption/decay_times/t_e_magnetic_axis/exponential/value ⇹sFLT_0DValue
Value
disruption/decay_times/t_e_magnetic_axis/exponential/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
disruption/decay_times/energy_thermalstructureThermal plasma energy content = 3/2 \* integral over the plasma […] (click to expand)
Thermal plasma energy content = 3/2 * integral over the plasma volume of the thermal pressure
disruption/decay_times/energy_thermal/linear_20_80sstructureDecay time defined as (t(0.2)-t(0.8))/0.6, where t(X) corresponds […] (click to expand)
Decay time defined as (t(0.2)-t(0.8))/0.6, where t(X) corresponds to the time where this quantity reaches X*100% of its pre-disruptive value
disruption/decay_times/energy_thermal/linear_20_80/value ⇹sFLT_0DValue
Value
disruption/decay_times/energy_thermal/linear_20_80/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
disruption/decay_times/energy_thermal/linear_customstructureDecay time defined as (t(X2)-t(X1))/(X1-X2), where t(Xj) corresponds […] (click to expand)
Decay time defined as (t(X2)-t(X1))/(X1-X2), where t(Xj) corresponds to the time where this quantity reaches Xj*100% of its pre-disruptive value
disruption/decay_times/energy_thermal/linear_custom/x1 ⇹1FLT_0DUser-defined parameter, see description of linear_custom
User-defined parameter, see description of linear_custom
disruption/decay_times/energy_thermal/linear_custom/x2 ⇹1FLT_0DUser-defined value, see description of linear_custom
User-defined value, see description of linear_custom
disruption/decay_times/energy_thermal/linear_custom/decay_timesstructureDecay time
Decay time
disruption/decay_times/energy_thermal/linear_custom/decay_time/value ⇹sFLT_0DValue
Value
disruption/decay_times/energy_thermal/linear_custom/decay_time/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
disruption/decay_times/energy_thermal/exponentialsstructureExponential decay time (tau) used when the process is described […] (click to expand)
Exponential decay time (tau) used when the process is described by an exponential function (exp(-(t-t0)/tau))). Here “t” is time and “t0” is the time where the decay process starts
disruption/decay_times/energy_thermal/exponential/value ⇹sFLT_0DValue
Value
disruption/decay_times/energy_thermal/exponential/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
disruption/halo_currentstructureCharacteristics of halo current
Characteristics of halo current
disruption/halo_current/fraction_pol_max1structureMaximum poloidal halo current normalized by the pre-disruption […] (click to expand)
Maximum poloidal halo current normalized by the pre-disruption toroidal plasma current
disruption/halo_current/fraction_pol_max/value ⇹1FLT_0DValue
Value
disruption/halo_current/fraction_pol_max/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
disruption/typestructureType of the disruption
Type of the disruption
This is an identifier. See disruption_type_identifier for the available options.
disruption/type/nameSTR_0DShort string identifier
Short string identifier
disruption/type/indexINT_0DInteger identifier (enumeration index within a list). […] (click to expand)
Integer identifier (enumeration index within a list). Private identifier values must be indicated by a negative index.
disruption/type/descriptionSTR_0DVerbose description
Verbose description
elmsstructureEdge Localized Modes related quantities
Edge Localized Modes related quantities
elms/frequencyHzstructureELMs frequency
ELMs frequency
elms/frequency/value(:) ⇹HzFLT_1DValue
Value
elms/frequency/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
elms/typestructureELMs type (I, II, III, …)
ELMs type (I, II, III, …)
elms/type/value(:)INT_1DValue
Value
elms/type/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
fusionstructureFusion reactions
Fusion reactions
fusion/powerWstructurePower coupled to the plasma by fusion reactions
Power coupled to the plasma by fusion reactions
fusion/power/value(:) ⇹WFLT_1DValue
Value
fusion/power/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
fusion/currentAstructureParallel current driven by this fusion reactions
Parallel current driven by this fusion reactions
fusion/current/value(:) ⇹AFLT_1DValue
Value
fusion/current/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
fusion/neutron_ratesstructureNeutron rates from various reactions
Neutron rates from various reactions
Changed in version 3.34.0: Renamed from neutron_fluxes
fusion/neutron_rates/totalHzstructureTotal neutron rate from all reactions
Total neutron rate from all reactions
fusion/neutron_rates/total/value(:) ⇹HzFLT_1DValue
Value
fusion/neutron_rates/total/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
fusion/neutron_rates/thermalHzstructureNeutron rate from all plasma thermal reactions
Neutron rate from all plasma thermal reactions
fusion/neutron_rates/thermal/value(:) ⇹HzFLT_1DValue
Value
fusion/neutron_rates/thermal/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
fusion/neutron_rates/ddstructureNeutron rates from DD reactions
Neutron rates from DD reactions
fusion/neutron_rates/dd/totalHzstructureTotal neutron rate coming from this reaction
Total neutron rate coming from this reaction
fusion/neutron_rates/dd/total/value(:) ⇹HzFLT_1DValue
Value
fusion/neutron_rates/dd/total/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
fusion/neutron_rates/dd/thermalHzstructureNeutron rate coming from thermal plasma
Neutron rate coming from thermal plasma
fusion/neutron_rates/dd/thermal/value(:) ⇹HzFLT_1DValue
Value
fusion/neutron_rates/dd/thermal/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
fusion/neutron_rates/dd/beam_thermalHzstructureNeutron rate coming from NBI beam - plasma reactions
Neutron rate coming from NBI beam - plasma reactions
fusion/neutron_rates/dd/beam_thermal/value(:) ⇹HzFLT_1DValue
Value
fusion/neutron_rates/dd/beam_thermal/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
fusion/neutron_rates/dd/beam_beamHzstructureNeutron rate coming from NBI beam self reactions
Neutron rate coming from NBI beam self reactions
fusion/neutron_rates/dd/beam_beam/value(:) ⇹HzFLT_1DValue
Value
fusion/neutron_rates/dd/beam_beam/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
fusion/neutron_rates/dtstructureNeutron rates from DT reactions
Neutron rates from DT reactions
fusion/neutron_rates/dt/totalHzstructureTotal neutron rate coming from this reaction
Total neutron rate coming from this reaction
fusion/neutron_rates/dt/total/value(:) ⇹HzFLT_1DValue
Value
fusion/neutron_rates/dt/total/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
fusion/neutron_rates/dt/thermalHzstructureNeutron rate coming from thermal plasma
Neutron rate coming from thermal plasma
fusion/neutron_rates/dt/thermal/value(:) ⇹HzFLT_1DValue
Value
fusion/neutron_rates/dt/thermal/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
fusion/neutron_rates/dt/beam_thermalHzstructureNeutron rate coming from NBI beam - plasma reactions
Neutron rate coming from NBI beam - plasma reactions
fusion/neutron_rates/dt/beam_thermal/value(:) ⇹HzFLT_1DValue
Value
fusion/neutron_rates/dt/beam_thermal/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
fusion/neutron_rates/dt/beam_beamHzstructureNeutron rate coming from NBI beam self reactions
Neutron rate coming from NBI beam self reactions
fusion/neutron_rates/dt/beam_beam/value(:) ⇹HzFLT_1DValue
Value
fusion/neutron_rates/dt/beam_beam/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
fusion/neutron_rates/ttstructureNeutron rates from TT reactions
Neutron rates from TT reactions
fusion/neutron_rates/tt/totalHzstructureTotal neutron rate coming from this reaction
Total neutron rate coming from this reaction
fusion/neutron_rates/tt/total/value(:) ⇹HzFLT_1DValue
Value
fusion/neutron_rates/tt/total/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
fusion/neutron_rates/tt/thermalHzstructureNeutron rate coming from thermal plasma
Neutron rate coming from thermal plasma
fusion/neutron_rates/tt/thermal/value(:) ⇹HzFLT_1DValue
Value
fusion/neutron_rates/tt/thermal/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
fusion/neutron_rates/tt/beam_thermalHzstructureNeutron rate coming from NBI beam - plasma reactions
Neutron rate coming from NBI beam - plasma reactions
fusion/neutron_rates/tt/beam_thermal/value(:) ⇹HzFLT_1DValue
Value
fusion/neutron_rates/tt/beam_thermal/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
fusion/neutron_rates/tt/beam_beamHzstructureNeutron rate coming from NBI beam self reactions
Neutron rate coming from NBI beam self reactions
fusion/neutron_rates/tt/beam_beam/value(:) ⇹HzFLT_1DValue
Value
fusion/neutron_rates/tt/beam_beam/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
fusion/neutron_power_totalWstructureTotal neutron power (from all reactions). […] (click to expand)
Total neutron power (from all reactions). Sum over each type of reaction (DD, DT, TT for thermal, beam-plasma, beam-beam, etc.) of the neutron production rate times the average neutron birth energy
fusion/neutron_power_total/value(:) ⇹WFLT_1DValue
Value
fusion/neutron_power_total/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_ratess^-1structureGas injection rates in equivalent electrons.s^-1
Gas injection rates in equivalent electrons.s^-1
gas_injection_rates/totalstructureTotal gas injection rate (sum over species)
Total gas injection rate (sum over species)
gas_injection_rates/total/value(:) ⇹s^-1FLT_1DValue
Value
gas_injection_rates/total/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_rates/midplanestructureGas injection rate from all valves located near the equatorial […] (click to expand)
Gas injection rate from all valves located near the equatorial midplane
gas_injection_rates/midplane/value(:) ⇹s^-1FLT_1DValue
Value
gas_injection_rates/midplane/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_rates/topstructureGas injection rate from all valves located near the top of the […] (click to expand)
Gas injection rate from all valves located near the top of the vaccuum chamber
gas_injection_rates/top/value(:) ⇹s^-1FLT_1DValue
Value
gas_injection_rates/top/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_rates/bottomstructureGas injection rate from all valves located near near the bottom […] (click to expand)
Gas injection rate from all valves located near near the bottom of the vaccuum chamber
gas_injection_rates/bottom/value(:) ⇹s^-1FLT_1DValue
Value
gas_injection_rates/bottom/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_rates/hydrogenstructureHydrogen
Hydrogen
gas_injection_rates/hydrogen/value(:) ⇹s^-1FLT_1DValue
Value
gas_injection_rates/hydrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_rates/deuteriumstructureDeuterium
Deuterium
gas_injection_rates/deuterium/value(:) ⇹s^-1FLT_1DValue
Value
gas_injection_rates/deuterium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_rates/tritiumstructureTritium
Tritium
gas_injection_rates/tritium/value(:) ⇹s^-1FLT_1DValue
Value
gas_injection_rates/tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_rates/helium_3structureHelium isotope with 3 nucleons
Helium isotope with 3 nucleons
gas_injection_rates/helium_3/value(:) ⇹s^-1FLT_1DValue
Value
gas_injection_rates/helium_3/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_rates/helium_4structureHelium isotope with 4 nucleons
Helium isotope with 4 nucleons
gas_injection_rates/helium_4/value(:) ⇹s^-1FLT_1DValue
Value
gas_injection_rates/helium_4/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_rates/impurity_seedingstructureFlag set to 1 if any gas other than H, D, T, He is puffed during […] (click to expand)
Flag set to 1 if any gas other than H, D, T, He is puffed during the pulse, 0 otherwise
gas_injection_rates/impurity_seeding/valueINT_0DValue
Value
gas_injection_rates/impurity_seeding/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_rates/berylliumstructureBeryllium
Beryllium
gas_injection_rates/beryllium/value(:) ⇹s^-1FLT_1DValue
Value
gas_injection_rates/beryllium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_rates/lithiumstructureLithium
Lithium
gas_injection_rates/lithium/value(:) ⇹s^-1FLT_1DValue
Value
gas_injection_rates/lithium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_rates/carbonstructureCarbon
Carbon
gas_injection_rates/carbon/value(:) ⇹s^-1FLT_1DValue
Value
gas_injection_rates/carbon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_rates/oxygenstructureOxygen
Oxygen
gas_injection_rates/oxygen/value(:) ⇹s^-1FLT_1DValue
Value
gas_injection_rates/oxygen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_rates/nitrogenstructureNitrogen
Nitrogen
gas_injection_rates/nitrogen/value(:) ⇹s^-1FLT_1DValue
Value
gas_injection_rates/nitrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_rates/neonstructureNeon
Neon
gas_injection_rates/neon/value(:) ⇹s^-1FLT_1DValue
Value
gas_injection_rates/neon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_rates/argonstructureArgon
Argon
gas_injection_rates/argon/value(:) ⇹s^-1FLT_1DValue
Value
gas_injection_rates/argon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_rates/xenonstructureXenon
Xenon
gas_injection_rates/xenon/value(:) ⇹s^-1FLT_1DValue
Value
gas_injection_rates/xenon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_rates/kryptonstructureKrypton
Krypton
gas_injection_rates/krypton/value(:) ⇹s^-1FLT_1DValue
Value
gas_injection_rates/krypton/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_rates/methanestructureMethane (CH4)
Methane (CH4)
gas_injection_rates/methane/value(:) ⇹s^-1FLT_1DValue
Value
gas_injection_rates/methane/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_rates/methane_carbon_13structureMethane (CH4 with carbon 13)
Methane (CH4 with carbon 13)
gas_injection_rates/methane_carbon_13/value(:) ⇹s^-1FLT_1DValue
Value
gas_injection_rates/methane_carbon_13/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_rates/methane_deuteratedstructureDeuterated methane (CD4)
Deuterated methane (CD4)
gas_injection_rates/methane_deuterated/value(:) ⇹s^-1FLT_1DValue
Value
gas_injection_rates/methane_deuterated/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_rates/silanestructureSilane (SiH4)
Silane (SiH4)
gas_injection_rates/silane/value(:) ⇹s^-1FLT_1DValue
Value
gas_injection_rates/silane/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_rates/ethylenestructureEthylene (C2H4)
Ethylene (C2H4)
gas_injection_rates/ethylene/value(:) ⇹s^-1FLT_1DValue
Value
gas_injection_rates/ethylene/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_rates/ethanestructureEthane (C2H6)
Ethane (C2H6)
gas_injection_rates/ethane/value(:) ⇹s^-1FLT_1DValue
Value
gas_injection_rates/ethane/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_rates/propanestructurePropane (C3H8)
Propane (C3H8)
gas_injection_rates/propane/value(:) ⇹s^-1FLT_1DValue
Value
gas_injection_rates/propane/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_rates/ammoniastructureAmmonia (NH3)
Ammonia (NH3)
gas_injection_rates/ammonia/value(:) ⇹s^-1FLT_1DValue
Value
gas_injection_rates/ammonia/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_rates/ammonia_deuteratedstructureDeuterated ammonia (ND3)
Deuterated ammonia (ND3)
gas_injection_rates/ammonia_deuterated/value(:) ⇹s^-1FLT_1DValue
Value
gas_injection_rates/ammonia_deuterated/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_accumulated1structureAccumulated injected gas since the plasma breakdown in equivalent […] (click to expand)
Accumulated injected gas since the plasma breakdown in equivalent electrons
gas_injection_accumulated/totalstructureTotal accumulated injected gas (sum over species)
Total accumulated injected gas (sum over species)
gas_injection_accumulated/total/value(:) ⇹1FLT_1DValue
Value
gas_injection_accumulated/total/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_accumulated/midplanestructureAccumulated gas injected from all valves located near the equatorial […] (click to expand)
Accumulated gas injected from all valves located near the equatorial midplane
gas_injection_accumulated/midplane/value(:) ⇹1FLT_1DValue
Value
gas_injection_accumulated/midplane/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_accumulated/topstructureAccumulated gas injected from all valves located near the top […] (click to expand)
Accumulated gas injected from all valves located near the top of the vacuum chamber
gas_injection_accumulated/top/value(:) ⇹1FLT_1DValue
Value
gas_injection_accumulated/top/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_accumulated/bottomstructureAccumulated gas injected from all valves located near near the […] (click to expand)
Accumulated gas injected from all valves located near near the bottom of the vacuum chamber
gas_injection_accumulated/bottom/value(:) ⇹1FLT_1DValue
Value
gas_injection_accumulated/bottom/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_accumulated/hydrogenstructureHydrogen
Hydrogen
gas_injection_accumulated/hydrogen/value(:) ⇹1FLT_1DValue
Value
gas_injection_accumulated/hydrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_accumulated/deuteriumstructureDeuterium
Deuterium
gas_injection_accumulated/deuterium/value(:) ⇹1FLT_1DValue
Value
gas_injection_accumulated/deuterium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_accumulated/tritiumstructureTritium
Tritium
gas_injection_accumulated/tritium/value(:) ⇹1FLT_1DValue
Value
gas_injection_accumulated/tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_accumulated/helium_3structureHelium isotope with 3 nucleons
Helium isotope with 3 nucleons
gas_injection_accumulated/helium_3/value(:) ⇹1FLT_1DValue
Value
gas_injection_accumulated/helium_3/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_accumulated/helium_4structureHelium isotope with 4 nucleons
Helium isotope with 4 nucleons
gas_injection_accumulated/helium_4/value(:) ⇹1FLT_1DValue
Value
gas_injection_accumulated/helium_4/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_accumulated/impurity_seedingstructureFlag set to 1 if any gas other than H, D, T, He is puffed during […] (click to expand)
Flag set to 1 if any gas other than H, D, T, He is puffed during the pulse, 0 otherwise
gas_injection_accumulated/impurity_seeding/valueINT_0DValue
Value
gas_injection_accumulated/impurity_seeding/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_accumulated/berylliumstructureBeryllium
Beryllium
gas_injection_accumulated/beryllium/value(:) ⇹1FLT_1DValue
Value
gas_injection_accumulated/beryllium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_accumulated/lithiumstructureLithium
Lithium
gas_injection_accumulated/lithium/value(:) ⇹1FLT_1DValue
Value
gas_injection_accumulated/lithium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_accumulated/carbonstructureCarbon
Carbon
gas_injection_accumulated/carbon/value(:) ⇹1FLT_1DValue
Value
gas_injection_accumulated/carbon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_accumulated/oxygenstructureOxygen
Oxygen
gas_injection_accumulated/oxygen/value(:) ⇹1FLT_1DValue
Value
gas_injection_accumulated/oxygen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_accumulated/nitrogenstructureNitrogen
Nitrogen
gas_injection_accumulated/nitrogen/value(:) ⇹1FLT_1DValue
Value
gas_injection_accumulated/nitrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_accumulated/neonstructureNeon
Neon
gas_injection_accumulated/neon/value(:) ⇹1FLT_1DValue
Value
gas_injection_accumulated/neon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_accumulated/argonstructureArgon
Argon
gas_injection_accumulated/argon/value(:) ⇹1FLT_1DValue
Value
gas_injection_accumulated/argon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_accumulated/xenonstructureXenon
Xenon
gas_injection_accumulated/xenon/value(:) ⇹1FLT_1DValue
Value
gas_injection_accumulated/xenon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_accumulated/kryptonstructureKrypton
Krypton
gas_injection_accumulated/krypton/value(:) ⇹1FLT_1DValue
Value
gas_injection_accumulated/krypton/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_accumulated/methanestructureMethane (CH4)
Methane (CH4)
gas_injection_accumulated/methane/value(:) ⇹1FLT_1DValue
Value
gas_injection_accumulated/methane/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_accumulated/methane_carbon_13structureMethane (CH4 with carbon 13)
Methane (CH4 with carbon 13)
gas_injection_accumulated/methane_carbon_13/value(:) ⇹1FLT_1DValue
Value
gas_injection_accumulated/methane_carbon_13/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_accumulated/methane_deuteratedstructureDeuterated methane (CD4)
Deuterated methane (CD4)
gas_injection_accumulated/methane_deuterated/value(:) ⇹1FLT_1DValue
Value
gas_injection_accumulated/methane_deuterated/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_accumulated/silanestructureSilane (SiH4)
Silane (SiH4)
gas_injection_accumulated/silane/value(:) ⇹1FLT_1DValue
Value
gas_injection_accumulated/silane/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_accumulated/ethylenestructureEthylene (C2H4)
Ethylene (C2H4)
gas_injection_accumulated/ethylene/value(:) ⇹1FLT_1DValue
Value
gas_injection_accumulated/ethylene/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_accumulated/ethanestructureEthane (C2H6)
Ethane (C2H6)
gas_injection_accumulated/ethane/value(:) ⇹1FLT_1DValue
Value
gas_injection_accumulated/ethane/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_accumulated/propanestructurePropane (C3H8)
Propane (C3H8)
gas_injection_accumulated/propane/value(:) ⇹1FLT_1DValue
Value
gas_injection_accumulated/propane/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_accumulated/ammoniastructureAmmonia (NH3)
Ammonia (NH3)
gas_injection_accumulated/ammonia/value(:) ⇹1FLT_1DValue
Value
gas_injection_accumulated/ammonia/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_accumulated/ammonia_deuteratedstructureDeuterated ammonia (ND3)
Deuterated ammonia (ND3)
gas_injection_accumulated/ammonia_deuterated/value(:) ⇹1FLT_1DValue
Value
gas_injection_accumulated/ammonia_deuterated/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_prefill1structureAccumulated injected gas during the prefill in equivalent electrons
Accumulated injected gas during the prefill in equivalent electrons
gas_injection_prefill/totalstructureTotal accumulated injected gas (sum over species)
Total accumulated injected gas (sum over species)
gas_injection_prefill/total/value ⇹1FLT_0DValue
Value
gas_injection_prefill/total/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_prefill/midplanestructureAccumulated gas injected from all valves located near the equatorial […] (click to expand)
Accumulated gas injected from all valves located near the equatorial midplane
gas_injection_prefill/midplane/value ⇹1FLT_0DValue
Value
gas_injection_prefill/midplane/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_prefill/topstructureAccumulated gas injected from all valves located near the top […] (click to expand)
Accumulated gas injected from all valves located near the top of the vacuum chamber
gas_injection_prefill/top/value ⇹1FLT_0DValue
Value
gas_injection_prefill/top/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_prefill/bottomstructureAccumulated gas injected from all valves located near near the […] (click to expand)
Accumulated gas injected from all valves located near near the bottom of the vacuum chamber
gas_injection_prefill/bottom/value ⇹1FLT_0DValue
Value
gas_injection_prefill/bottom/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_prefill/hydrogenstructureHydrogen
Hydrogen
gas_injection_prefill/hydrogen/value ⇹1FLT_0DValue
Value
gas_injection_prefill/hydrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_prefill/deuteriumstructureDeuterium
Deuterium
gas_injection_prefill/deuterium/value ⇹1FLT_0DValue
Value
gas_injection_prefill/deuterium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_prefill/tritiumstructureTritium
Tritium
gas_injection_prefill/tritium/value ⇹1FLT_0DValue
Value
gas_injection_prefill/tritium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_prefill/helium_3structureHelium isotope with 3 nucleons
Helium isotope with 3 nucleons
gas_injection_prefill/helium_3/value ⇹1FLT_0DValue
Value
gas_injection_prefill/helium_3/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_prefill/helium_4structureHelium isotope with 4 nucleons
Helium isotope with 4 nucleons
gas_injection_prefill/helium_4/value ⇹1FLT_0DValue
Value
gas_injection_prefill/helium_4/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_prefill/impurity_seedingstructureFlag set to 1 if any gas other than H, D, T, He is puffed during […] (click to expand)
Flag set to 1 if any gas other than H, D, T, He is puffed during the prefill, 0 otherwise
gas_injection_prefill/impurity_seeding/valueINT_0DValue
Value
gas_injection_prefill/impurity_seeding/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_prefill/berylliumstructureBeryllium
Beryllium
gas_injection_prefill/beryllium/value ⇹1FLT_0DValue
Value
gas_injection_prefill/beryllium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_prefill/lithiumstructureLithium
Lithium
gas_injection_prefill/lithium/value ⇹1FLT_0DValue
Value
gas_injection_prefill/lithium/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_prefill/carbonstructureCarbon
Carbon
gas_injection_prefill/carbon/value ⇹1FLT_0DValue
Value
gas_injection_prefill/carbon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_prefill/oxygenstructureOxygen
Oxygen
gas_injection_prefill/oxygen/value ⇹1FLT_0DValue
Value
gas_injection_prefill/oxygen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_prefill/nitrogenstructureNitrogen
Nitrogen
gas_injection_prefill/nitrogen/value ⇹1FLT_0DValue
Value
gas_injection_prefill/nitrogen/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_prefill/neonstructureNeon
Neon
gas_injection_prefill/neon/value ⇹1FLT_0DValue
Value
gas_injection_prefill/neon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_prefill/argonstructureArgon
Argon
gas_injection_prefill/argon/value ⇹1FLT_0DValue
Value
gas_injection_prefill/argon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_prefill/xenonstructureXenon
Xenon
gas_injection_prefill/xenon/value ⇹1FLT_0DValue
Value
gas_injection_prefill/xenon/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_prefill/kryptonstructureKrypton
Krypton
gas_injection_prefill/krypton/value ⇹1FLT_0DValue
Value
gas_injection_prefill/krypton/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_prefill/methanestructureMethane (CH4)
Methane (CH4)
gas_injection_prefill/methane/value ⇹1FLT_0DValue
Value
gas_injection_prefill/methane/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_prefill/methane_carbon_13structureMethane (CH4 with carbon 13)
Methane (CH4 with carbon 13)
gas_injection_prefill/methane_carbon_13/value ⇹1FLT_0DValue
Value
gas_injection_prefill/methane_carbon_13/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_prefill/methane_deuteratedstructureDeuterated methane (CD4)
Deuterated methane (CD4)
gas_injection_prefill/methane_deuterated/value ⇹1FLT_0DValue
Value
gas_injection_prefill/methane_deuterated/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_prefill/silanestructureSilane (SiH4)
Silane (SiH4)
gas_injection_prefill/silane/value ⇹1FLT_0DValue
Value
gas_injection_prefill/silane/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_prefill/ethylenestructureEthylene (C2H4)
Ethylene (C2H4)
gas_injection_prefill/ethylene/value ⇹1FLT_0DValue
Value
gas_injection_prefill/ethylene/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_prefill/ethanestructureEthane (C2H6)
Ethane (C2H6)
gas_injection_prefill/ethane/value ⇹1FLT_0DValue
Value
gas_injection_prefill/ethane/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_prefill/propanestructurePropane (C3H8)
Propane (C3H8)
gas_injection_prefill/propane/value ⇹1FLT_0DValue
Value
gas_injection_prefill/propane/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_prefill/ammoniastructureAmmonia (NH3)
Ammonia (NH3)
gas_injection_prefill/ammonia/value ⇹1FLT_0DValue
Value
gas_injection_prefill/ammonia/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
gas_injection_prefill/ammonia_deuteratedstructureDeuterated ammonia (ND3)
Deuterated ammonia (ND3)
gas_injection_prefill/ammonia_deuterated/value ⇹1FLT_0DValue
Value
gas_injection_prefill/ammonia_deuterated/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drivestructureHeating and current drive parameters
Heating and current drive parameters
heating_current_drive/ec(i1)AoSSet of ECRH/ECCD launchers
Set of ECRH/ECCD launchers
heating_current_drive/ec(i1)/frequencyHzstructureECRH frequency
ECRH frequency
heating_current_drive/ec(i1)/frequency/value(:) ⇹HzFLT_1DValue
Value
heating_current_drive/ec(i1)/frequency/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/ec(i1)/position1structurePosition of the maximum of the ECRH power deposition, in rho_tor_norm
Position of the maximum of the ECRH power deposition, in rho_tor_norm
heating_current_drive/ec(i1)/position/value(:) ⇹1FLT_1DValue
Value
heating_current_drive/ec(i1)/position/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/ec(i1)/polarizationstructurePolarization of the ECRH waves (0 = O mode, 1 = X mode)
Polarization of the ECRH waves (0 = O mode, 1 = X mode)
Changed in version 4.0.0: Renamed from polarisation
heating_current_drive/ec(i1)/polarization/value(:)INT_1DValue
Value
heating_current_drive/ec(i1)/polarization/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/ec(i1)/harmonicstructureHarmonic number of the absorbed ECRH waves
Harmonic number of the absorbed ECRH waves
heating_current_drive/ec(i1)/harmonic/value(:)INT_1DValue
Value
heating_current_drive/ec(i1)/harmonic/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/ec(i1)/phiradstructureToroidal angle of ECRH at resonance
Toroidal angle of ECRH at resonance
Changed in version 3.42.0: Renamed from angle_tor
heating_current_drive/ec(i1)/phi/value(:) ⇹radFLT_1DValue
Value
heating_current_drive/ec(i1)/phi/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/ec(i1)/angle_polradstructurePoloidal angle of ECRH at resonance
Poloidal angle of ECRH at resonance
heating_current_drive/ec(i1)/angle_pol/value(:) ⇹radFLT_1DValue
Value
heating_current_drive/ec(i1)/angle_pol/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/ec(i1)/powerWstructureElectron cyclotron heating power coupled to the plasma from this […] (click to expand)
Electron cyclotron heating power coupled to the plasma from this launcher
heating_current_drive/ec(i1)/power/value(:) ⇹WFLT_1DValue
Value
heating_current_drive/ec(i1)/power/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/ec(i1)/power_launchedWstructureElectron cyclotron heating power launched into the vacuum vessel […] (click to expand)
Electron cyclotron heating power launched into the vacuum vessel from this launcher
heating_current_drive/ec(i1)/power_launched/value(:) ⇹WFLT_1DValue
Value
heating_current_drive/ec(i1)/power_launched/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/ec(i1)/currentAstructureParallel current driven by EC waves
Parallel current driven by EC waves
heating_current_drive/ec(i1)/current/value(:) ⇹AFLT_1DValue
Value
heating_current_drive/ec(i1)/current/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/ec(i1)/energy_fastJstructureFast particle energy content driven by EC waves
Fast particle energy content driven by EC waves
heating_current_drive/ec(i1)/energy_fast/value(:) ⇹JFLT_1DValue
Value
heating_current_drive/ec(i1)/energy_fast/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/nbi(i1)AoSSet of NBI units
Set of NBI units
heating_current_drive/nbi(i1)/speciesstructureInjected species
Injected species
heating_current_drive/nbi(i1)/species/austructureMass of atom
Mass of atom
heating_current_drive/nbi(i1)/species/a/value ⇹uFLT_0DValue
Value
heating_current_drive/nbi(i1)/species/a/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/nbi(i1)/species/z_nestructureNuclear charge
Nuclear charge
heating_current_drive/nbi(i1)/species/z_n/value ⇹eFLT_0DValue
Value
heating_current_drive/nbi(i1)/species/z_n/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/nbi(i1)/species/namestructureString identifying the species (e.g. […] (click to expand)
String identifying the species (e.g. H, D, T, …)
Changed in version 3.42.0: Renamed from label
heating_current_drive/nbi(i1)/species/name/valueSTR_0DValue
Value
heating_current_drive/nbi(i1)/species/name/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/nbi(i1)/powerWstructureNBI power coupled to the plasma by this unit (i.e. […] (click to expand)
NBI power coupled to the plasma by this unit (i.e. without shine-through and fast ion losses)
heating_current_drive/nbi(i1)/power/value(:) ⇹WFLT_1DValue
Value
heating_current_drive/nbi(i1)/power/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/nbi(i1)/power_launchedWstructureNBI power launched into the vacuum vessel from this unit
NBI power launched into the vacuum vessel from this unit
heating_current_drive/nbi(i1)/power_launched/value(:) ⇹WFLT_1DValue
Value
heating_current_drive/nbi(i1)/power_launched/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/nbi(i1)/currentAstructureParallel current driven by this NBI unit
Parallel current driven by this NBI unit
heating_current_drive/nbi(i1)/current/value(:) ⇹AFLT_1DValue
Value
heating_current_drive/nbi(i1)/current/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/nbi(i1)/positionstructureR, Z, Phi position of the NBI unit centre
R, Z, Phi position of the NBI unit centre
heating_current_drive/nbi(i1)/position/rmstructureMajor radius
Major radius
heating_current_drive/nbi(i1)/position/r/value ⇹mFLT_0DValue
Value
heating_current_drive/nbi(i1)/position/r/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/nbi(i1)/position/zmstructureHeight
Height
heating_current_drive/nbi(i1)/position/z/value ⇹mFLT_0DValue
Value
heating_current_drive/nbi(i1)/position/z/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/nbi(i1)/position/phiradstructureToroidal angle
Toroidal angle
heating_current_drive/nbi(i1)/position/phi/value ⇹radFLT_0DValue
Value
heating_current_drive/nbi(i1)/position/phi/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/nbi(i1)/tangency_radiusmstructureTangency radius (major radius where the central line of a NBI […] (click to expand)
Tangency radius (major radius where the central line of a NBI unit is tangent to a circle around the torus)
heating_current_drive/nbi(i1)/tangency_radius/value ⇹mFLT_0DValue
Value
heating_current_drive/nbi(i1)/tangency_radius/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/nbi(i1)/angleradstructureAngle of inclination between a beamlet at the centre of the injection […] (click to expand)
Angle of inclination between a beamlet at the centre of the injection unit surface and the horizontal plane
heating_current_drive/nbi(i1)/angle/value ⇹radFLT_0DValue
Value
heating_current_drive/nbi(i1)/angle/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/nbi(i1)/directionstructureDirection of the beam seen from above the torus: -1 = clockwise; […] (click to expand)
Direction of the beam seen from above the torus: -1 = clockwise; 1 = counter clockwise
heating_current_drive/nbi(i1)/direction/valueINT_0DValue
Value
heating_current_drive/nbi(i1)/direction/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/nbi(i1)/energyeVstructureFull energy of the injected species (acceleration of a single […] (click to expand)
Full energy of the injected species (acceleration of a single atom)
heating_current_drive/nbi(i1)/energy/value(:) ⇹eVFLT_1DValue
Value
heating_current_drive/nbi(i1)/energy/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/nbi(i1)/beam_current_fraction1structureFractions of beam current distributed among the different energies, […] (click to expand)
Fractions of beam current distributed among the different energies, the first index corresponds to the fast neutrals energy (1:full, 2: half, 3: one third)
heating_current_drive/nbi(i1)/beam_current_fraction/value(:,:) ⇹1FLT_2DValue
Value
heating_current_drive/nbi(i1)/beam_current_fraction/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/nbi(i1)/beam_power_fraction1structureFractions of beam power distributed among the different energies, […] (click to expand)
Fractions of beam power distributed among the different energies, the first index corresponds to the fast neutrals energy (1:full, 2: half, 3: one third)
heating_current_drive/nbi(i1)/beam_power_fraction/value(:,:) ⇹1FLT_2DValue
Value
heating_current_drive/nbi(i1)/beam_power_fraction/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/ic(i1)AoSSet of ICRH launchers
Set of ICRH launchers
heating_current_drive/ic(i1)/frequencyHzstructureICRH frequency
ICRH frequency
heating_current_drive/ic(i1)/frequency/value(:) ⇹HzFLT_1DValue
Value
heating_current_drive/ic(i1)/frequency/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/ic(i1)/position1structurePosition of the maximum of the ICRH power deposition, in rho_tor_norm
Position of the maximum of the ICRH power deposition, in rho_tor_norm
heating_current_drive/ic(i1)/position/value(:) ⇹1FLT_1DValue
Value
heating_current_drive/ic(i1)/position/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/ic(i1)/n_phistructureMain toroidal mode number of IC waves. […] (click to expand)
Main toroidal mode number of IC waves. The wave vector toroidal component is defined as k_phi = n_phi grad phi where phi is the toroidal angle so that a positive n_tor means a wave propagating in the positive phi direction
Changed in version 3.42.0: Renamed from n_tor
heating_current_drive/ic(i1)/n_phi/value(:)INT_1DValue
Value
heating_current_drive/ic(i1)/n_phi/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/ic(i1)/k_perpendicularm^-1structureMain perpendicular wave number of IC waves
Main perpendicular wave number of IC waves
heating_current_drive/ic(i1)/k_perpendicular/value(:) ⇹m^-1FLT_1DValue
Value
heating_current_drive/ic(i1)/k_perpendicular/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/ic(i1)/e_field_plus_minus_ratio1structureAverage E+/E- power ratio of IC waves
Average E+/E- power ratio of IC waves
heating_current_drive/ic(i1)/e_field_plus_minus_ratio/value(:) ⇹1FLT_1DValue
Value
heating_current_drive/ic(i1)/e_field_plus_minus_ratio/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/ic(i1)/harmonicstructureHarmonic number of the absorbed ICRH waves
Harmonic number of the absorbed ICRH waves
heating_current_drive/ic(i1)/harmonic/value(:)INT_1DValue
Value
heating_current_drive/ic(i1)/harmonic/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/ic(i1)/phaseradstructurePhase between straps
Phase between straps
heating_current_drive/ic(i1)/phase/value(:) ⇹radFLT_1DValue
Value
heating_current_drive/ic(i1)/phase/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/ic(i1)/powerWstructureIC heating power coupled to the plasma from this launcher
IC heating power coupled to the plasma from this launcher
heating_current_drive/ic(i1)/power/value(:) ⇹WFLT_1DValue
Value
heating_current_drive/ic(i1)/power/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/ic(i1)/power_launchedWstructureIC heating power launched into the vacuum vessel from this launcher
IC heating power launched into the vacuum vessel from this launcher
heating_current_drive/ic(i1)/power_launched/value(:) ⇹WFLT_1DValue
Value
heating_current_drive/ic(i1)/power_launched/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/ic(i1)/currentAstructureParallel current driven by IC waves
Parallel current driven by IC waves
heating_current_drive/ic(i1)/current/value(:) ⇹AFLT_1DValue
Value
heating_current_drive/ic(i1)/current/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/ic(i1)/energy_fastJstructureFast particle energy content driven by IC waves
Fast particle energy content driven by IC waves
heating_current_drive/ic(i1)/energy_fast/value(:) ⇹JFLT_1DValue
Value
heating_current_drive/ic(i1)/energy_fast/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/lh(i1)AoSSet of LHCD launchers
Set of LHCD launchers
heating_current_drive/lh(i1)/frequencyHzstructureLH wave frequency
LH wave frequency
heating_current_drive/lh(i1)/frequency/value(:) ⇹HzFLT_1DValue
Value
heating_current_drive/lh(i1)/frequency/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/lh(i1)/position1structurePosition of the maximum of the LH power deposition, in rho_tor_norm
Position of the maximum of the LH power deposition, in rho_tor_norm
heating_current_drive/lh(i1)/position/value(:) ⇹1FLT_1DValue
Value
heating_current_drive/lh(i1)/position/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/lh(i1)/n_parallel1structureMain parallel refractive index of LH waves at launch
Main parallel refractive index of LH waves at launch
heating_current_drive/lh(i1)/n_parallel/value(:) ⇹1FLT_1DValue
Value
heating_current_drive/lh(i1)/n_parallel/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/lh(i1)/powerWstructureLH heating power coupled to the plasma from this launcher
LH heating power coupled to the plasma from this launcher
heating_current_drive/lh(i1)/power/value(:) ⇹WFLT_1DValue
Value
heating_current_drive/lh(i1)/power/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/lh(i1)/power_launchedWstructureLH heating power launched into the vacuum vessel from this launcher
LH heating power launched into the vacuum vessel from this launcher
heating_current_drive/lh(i1)/power_launched/value(:) ⇹WFLT_1DValue
Value
heating_current_drive/lh(i1)/power_launched/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/lh(i1)/currentAstructureParallel current driven by LH waves
Parallel current driven by LH waves
heating_current_drive/lh(i1)/current/value(:) ⇹AFLT_1DValue
Value
heating_current_drive/lh(i1)/current/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/lh(i1)/energy_fastJstructureFast particle energy content driven by LH waves
Fast particle energy content driven by LH waves
heating_current_drive/lh(i1)/energy_fast/value(:) ⇹JFLT_1DValue
Value
heating_current_drive/lh(i1)/energy_fast/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/power_ecWstructureTotal EC power coupled to the plasma
Total EC power coupled to the plasma
heating_current_drive/power_ec/value(:) ⇹WFLT_1DValue
Value
heating_current_drive/power_ec/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/power_launched_ecWstructureTotal EC power launched from EC launchers into the vacuum vessel
Total EC power launched from EC launchers into the vacuum vessel
heating_current_drive/power_launched_ec/value(:) ⇹WFLT_1DValue
Value
heating_current_drive/power_launched_ec/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/power_nbiWstructureTotal NBI power coupled to the plasma
Total NBI power coupled to the plasma
heating_current_drive/power_nbi/value(:) ⇹WFLT_1DValue
Value
heating_current_drive/power_nbi/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/power_launched_nbiWstructureTotal NBI power launched from neutral beam injectors into the […] (click to expand)
Total NBI power launched from neutral beam injectors into the vacuum vessel
heating_current_drive/power_launched_nbi/value(:) ⇹WFLT_1DValue
Value
heating_current_drive/power_launched_nbi/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/power_launched_nbi_co_injected_ratio1structureRatio of co-injected beam launched power to total NBI launched […] (click to expand)
Ratio of co-injected beam launched power to total NBI launched power. Is set to 1 for purely perpendicular injection
heating_current_drive/power_launched_nbi_co_injected_ratio/value(:) ⇹1FLT_1DValue
Value
heating_current_drive/power_launched_nbi_co_injected_ratio/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/power_icWstructureTotal IC power coupled to the plasma
Total IC power coupled to the plasma
heating_current_drive/power_ic/value(:) ⇹WFLT_1DValue
Value
heating_current_drive/power_ic/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/power_launched_icWstructureTotal IC power launched from IC antennas into the vacuum vessel
Total IC power launched from IC antennas into the vacuum vessel
heating_current_drive/power_launched_ic/value(:) ⇹WFLT_1DValue
Value
heating_current_drive/power_launched_ic/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/power_lhWstructureTotal LH power coupled to the plasma
Total LH power coupled to the plasma
heating_current_drive/power_lh/value(:) ⇹WFLT_1DValue
Value
heating_current_drive/power_lh/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/power_launched_lhWstructureTotal LH power launched from LH antennas into the vacuum vessel
Total LH power launched from LH antennas into the vacuum vessel
heating_current_drive/power_launched_lh/value(:) ⇹WFLT_1DValue
Value
heating_current_drive/power_launched_lh/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
heating_current_drive/power_additionalWstructureTotal additional external power (NBI+EC+IC+LH, without ohmic) […] (click to expand)
Total additional external power (NBI+EC+IC+LH, without ohmic) coupled to the plasma
heating_current_drive/power_additional/value(:) ⇹WFLT_1DValue
Value
heating_current_drive/power_additional/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
kicksstructureVertical kicks of the plasma position
Vertical kicks of the plasma position
kicks/occurrenceHzstructureFlag set to 1 if vertical kicks of the plasma position are used […] (click to expand)
Flag set to 1 if vertical kicks of the plasma position are used during the pulse, 0 otherwise
kicks/occurrence/valueINT_0DValue
Value
kicks/occurrence/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
pelletsstructurePellet related quantities
Pellet related quantities
pellets/occurrenceHzstructureFlag set to 1 if there is any pellet injected during the pulse, […] (click to expand)
Flag set to 1 if there is any pellet injected during the pulse, 0 otherwise
pellets/occurrence/valueINT_0DValue
Value
pellets/occurrence/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
rmpsstructureResonant magnetic perturbations related quantities
Resonant magnetic perturbations related quantities
rmps/occurrenceHzstructureFlag set to 1 if resonant magnetic perturbations are used during […] (click to expand)
Flag set to 1 if resonant magnetic perturbations are used during the pulse, 0 otherwise
rmps/occurrence/valueINT_0DValue
Value
rmps/occurrence/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
runawaysstructureRunaway electrons
Runaway electrons
runaways/particles1structureNumber of runaway electrons
Number of runaway electrons
runaways/particles/value(:) ⇹1FLT_1DValue
Value
runaways/particles/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
runaways/currentAstructureParallel current driven by the runaway electrons
Parallel current driven by the runaway electrons
runaways/current/value(:) ⇹AFLT_1DValue
Value
runaways/current/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
runaways/current_phi_maxAstructureMaximum toroidal current carried by runaway electrons during […] (click to expand)
Maximum toroidal current carried by runaway electrons during the pulse
runaways/current_phi_max/value ⇹AFLT_0DValue
Value
runaways/current_phi_max/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
scrape_off_layerstructureScrape-Off-Layer (SOL) characteristics
Scrape-Off-Layer (SOL) characteristics
scrape_off_layer/t_e_decay_lengthmstructureElectron temperature radial decay length inv(grad Te/Te)
Electron temperature radial decay length inv(grad Te/Te)
scrape_off_layer/t_e_decay_length/value(:) ⇹mFLT_1DValue
Value
scrape_off_layer/t_e_decay_length/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
scrape_off_layer/t_i_average_decay_lengthmstructureIon temperature (average over ion species) radial decay length […] (click to expand)
Ion temperature (average over ion species) radial decay length inv(grad Ti/Ti)
scrape_off_layer/t_i_average_decay_length/value(:) ⇹mFLT_1DValue
Value
scrape_off_layer/t_i_average_decay_length/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
scrape_off_layer/n_e_decay_lengthmstructureElectron density radial decay length inv(grad ne/ne)
Electron density radial decay length inv(grad ne/ne)
scrape_off_layer/n_e_decay_length/value(:) ⇹mFLT_1DValue
Value
scrape_off_layer/n_e_decay_length/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
scrape_off_layer/n_i_total_decay_lengthmstructureIon density radial decay length inv(grad ni/ni)
Ion density radial decay length inv(grad ni/ni)
scrape_off_layer/n_i_total_decay_length/value(:) ⇹mFLT_1DValue
Value
scrape_off_layer/n_i_total_decay_length/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
scrape_off_layer/heat_flux_e_decay_lengthmstructureElectron heat flux radial decay length inv(grad qe/qe)
Electron heat flux radial decay length inv(grad qe/qe)
scrape_off_layer/heat_flux_e_decay_length/value(:) ⇹mFLT_1DValue
Value
scrape_off_layer/heat_flux_e_decay_length/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
scrape_off_layer/heat_flux_i_decay_lengthmstructureIon heat flux radial decay length inv(grad qi/qi)
Ion heat flux radial decay length inv(grad qi/qi)
scrape_off_layer/heat_flux_i_decay_length/value(:) ⇹mFLT_1DValue
Value
scrape_off_layer/heat_flux_i_decay_length/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
scrape_off_layer/power_radiatedWstructurePower radiated from the SOL
Power radiated from the SOL
scrape_off_layer/power_radiated/value(:) ⇹WFLT_1DValue
Value
scrape_off_layer/power_radiated/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
scrape_off_layer/pressure_neutralPastructureNeutral pressure in the SOL
Neutral pressure in the SOL
scrape_off_layer/pressure_neutral/value(:) ⇹PaFLT_1DValue
Value
scrape_off_layer/pressure_neutral/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
wallstructureWall characteristics
Wall characteristics
wall/materialstructureWall material
Wall material
This is an identifier. See materials_identifier for the available options.
wall/material/nameSTR_0DShort string identifier
Short string identifier
wall/material/indexINT_0DInteger identifier (enumeration index within a list). […] (click to expand)
Integer identifier (enumeration index within a list). Private identifier values must be indicated by a negative index.
wall/material/descriptionSTR_0DVerbose description
Verbose description
wall/evaporationstructureChemical formula of the evaporated material or gas used to cover […] (click to expand)
Chemical formula of the evaporated material or gas used to cover the vaccum vessel wall. NONE for no evaporation.
wall/evaporation/valueSTR_0DValue
Value
wall/evaporation/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
limiterstructureLimiter characteristics
Limiter characteristics
limiter/materialstructureLimiter material
Limiter material
This is an identifier. See materials_identifier for the available options.
limiter/material/nameSTR_0DShort string identifier
Short string identifier
limiter/material/indexINT_0DInteger identifier (enumeration index within a list). […] (click to expand)
Integer identifier (enumeration index within a list). Private identifier values must be indicated by a negative index.
limiter/material/descriptionSTR_0DVerbose description
Verbose description
time_breakdownsstructureTime of the plasma breakdown
Time of the plasma breakdown
time_breakdown/value ⇹sFLT_0DValue
Value
time_breakdown/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
plasma_durationsstructureDuration of existence of a confined plasma during the pulse
Duration of existence of a confined plasma during the pulse
plasma_duration/value ⇹sFLT_0DValue
Value
plasma_duration/sourceSTR_0DSource of the data (any comment describing the origin of the […] (click to expand)
Source of the data (any comment describing the origin of the data : code, path to diagnostic signals, processing method, …)
time_width(:) ⇹sFLT_1DIn case the time-dependent quantities of this IDS are averaged […] (click to expand)
In case the time-dependent quantities of this IDS are averaged over a time interval, this node is the width of this time interval (empty otherwise). By convention, the time interval starts at time-time_width and ends at time.
codestructure
See common IDS structure reference: code.
time(:)sFLT_1DGeneric time
Generic time
